Názvosloví
1 Čočka objektivu
2
Sluneční clona objektivu (kluzná)
3 Značka pro nasazení objektivu
okuláru
4 Okulár
5 Uvolňovací tlačítko objektivu
okuláru
6 Zaostřovací kroužek
7 Patice k upevnění na stativ
8 Svorka (pouze úhlový typ)
9 Otvor se závitem pro stativ (1/4”)
(1 otvor)
0 Otvor pro kolíky video (2 otvory)
* Toto schéma zobrazuje připojený okulár.
8
9
0
1
2
4
3
7
6
(Přímý)
5
1
2
4
7
6
(Úhlový)
3
