SPECIFICATIONS
RECOMMENDED AMPLIFIER POWER
Five to 100 watts per channel
NOMINAL IMPEDANCE
8 Ohms
FREQUENCY RESPONSE
110Hz to 21kHz, plus or minus 3 dB (on axis)
SENSITIVITY
89 decibels for 2.83 volts of Pink Noise, measured at 1 meter on axis
WIRING REQUIREMENTS
Sixteen to 18 gauge 2-conductor (unshielded or shielded) wire for runs up to 80
feet. Fourteen gauge 2-conductor (unshielded or shielded) wire for runs up to
200 feet.
TEMPERATURE EXTREMES
-50° to 200° Fahrenheit
DIMENSIONS (Speaker without bracket)
7" Wide x 9-1/4" High x 5-11/16" Deep
DIMENSIONS (Speaker with bracket)
7" Wide x 9-1/4" High x 6-5/8" Deep
WEIGHT (Speaker and bracket)
4 lbs. 12 oz. each
SPECIFICATIONS
19
