SC3000 26” Disc / 28” Cyl. 9098827000(2)2010-12
9
INSTRUCTIONS FOR USE
ENGLISH
ACCESSORIES/OPTIONS
In addition to the standard components, the machine can be equipped with the following accessories/options, according to the
machine specifi c use:
GEL/AGM batteries –
Brushes and cylindrical brushes of different materials –
Pads of different materials –
Squeegee blades of different materials –
Flashing light –
Mop a trash kit –
0.9 HP (670 W) vacuum system motor –
For further information concerning the optional accessories, contact an authorized Retailer.
TECHNICAL DATA
General technical data
Description 26” Disc 28” Cyl.
Cleaning width 26 in (660 mm) 28 in (710 mm)
Squeegee width 35 in (890 mm)
Solution/clean water tank capacity 21 USgal (80 liters)
Solution fl ow 0.26 - 0.8 USgal/min (1 - 3 liters/min)
Rear wheel diameter 9.8 in (250 mm)
Front wheel specifi c pressure on the fl oor 72 psi (0.5 N/mm
2
)
Rear wheel specifi c pressure on the fl oor 130 psi (0.9 N/mm
2
)
Front steering, driving and braking wheel diameter 8.8 in (225 mm)
Vacuum system motor power 0.56 HP (420 W)
Drive system motor power 0.4 HP (300 W)
Maximum speed 3.7 mph (6 km/h)
Maximum gradient when working 2% (1,14°)
Sound pressure level at workstation
(ISO 11201, ISO 4871, EN 60335-2-72) (LpA)
65 dB(A) ± 3 dB(A)
Machine sound pressure level
(ISO 3744, ISO 4871, EN 60335-2-72) (LwA)
82 dB(A)
Vibration level at the operator’s arms
(ISO 5349-1, EN 60335-2-72)
< 98,4 in/s
2
(< 2.5 m/s
2
)
Vibration level at the operator’s body
(ISO 2631-1, EN 60335-2-72)
3.1 in/s2 (0.8 m/s2)
Battery compartment size (length x width x height) 14.9 x 21.2 x 11.8 in (380 x 540 x 300 mm)
Battery type
4 6 V batteries, 180 Ah C5 (WET)
4 6 V batteries, 180 Ah C5 (GEL/AGM)
Vacuum system capacity 0.0098 MPa (1,000 mmH
2
O)
Machine height 46.8 in (1,190 mm)
Machine maximum length 53.5 in (1,360 mm)
Machine width without squeegee 26.4 in (670 mm) 31.9 in (810 mm)
Technical data for machines with brush/pad-holder deck
Description 26” Disc
Brush/pad diameter 13 in (330 mm)
Weight without batteries and with empty tanks 385.8 lb (175 kg)
Maximum weight with batteries, full tanks and operator (75 kg) (GVW) 983.2 lb (446 kg)
Brush/pad motor power 2 x 0.53 HP (2 x 400 W)
Brush/pad-holder speed 230 rpm
Brush/pad-holder pressure with extra-pressure function turned off 66.1 lb (30 kg)
Brush/pad-holder pressure with extra-pressure function turned on 105.8 lb (48 kg)
