2002 Nokia Corporation. All rights reserved.
U.S. English
13
CONNECT THE DATA CABLE
1 Attach the Nokia 31 terminal data cable to the data adapter.
2 Connect the other end of the data cable to the serial port of a PC
or other compatible device.
Note:You should only use the data cable (RS-232) supplied
by Nokia.
C
ONNECT
THE
POWER
The power connector for the Nokia 31 terminal is located at the back
end of the terminal, next to the data cable connector. When the Nokia
31 terminal is mounted into the data adapter, the power interface is
found under the edge of the data adapter.
1 Connect the power cord from the power supply to the terminal.
2 Connect the power supply to an AC wall outlet.
MOUNT THE TERMINAL
The Nokia 31 terminal can be mounted either horizontally or vertically on a suitable flat surface.
