Nokia Asha 200 (RM-761)
Nokia Asha 201 (RM-799/RM-
800)
Service Manual Level 1&2
21
Co nf id e nt ial | Co pyrig ht © 2011 Nokia | A ll rights reserved
V e rs io n 1 .0
12. SOLDER COMPONENTS
X7454F2051
G2200
X2500
V2424
V2428
V2425V2422
V2423V2427V2426
V2421
TOP
BOTTOM
v1.0
