Nokia X5-01 Service Manual

Nokia X5-01
RM-627, RM-648
Service Manual Level 1&2
4 Confidential | Copyright © 2010 Nokia | All rights reserved Version 4.0
1. COPYRIGHT
Copyright © 2010 Nokia. All rights reserved.
Reproduction, transfer, distribution or storage of part or all of the contents in this document in
any form without the prior written permission of Nokia is prohibited.
Nokia, Nokia Connecting People, and Nokia X and Y are trademarks or registered trademarks of
Nokia Corporation. Other product and company names mentioned herein may be trademarks or
tradenames of their respective owners.
Nokia operates a policy of continuous development. Nokia reserves the right to make changes
and improvements to any of the products described in this document without prior notice.
Under no circumstances shall Nokia be responsible for any loss of data or income or any special,
incidental, consequential or indirect damages howsoever caused.
The contents of this document are provided “as is”. Except as required by applicable law, no
warranties of any kind, either express or implied, including, but not limited to, the implied
warranties of merchantability and fitness for a particular purpose, are made in relation to the
accuracy, reliability or contents of this document. Nokia reserves the right to revise this
document or withdraw it at any time without prior notice.
The availability of particular products may vary by region.
IMPORTANT
This document is intended for use by qualified service personnel only.

Nokia X5-01 Specifications

General

Panel type	TFT
Display diagonal	2.36 \
Display resolution	320 x 240 pixels
Display number of colors	262144 colors
Ringer type	Polyphonic
Processor frequency	0.6 GHz
Internal memory	200 MB
Maximum memory card size	32 GB
Rear camera type	Single camera
Rear camera resolution	2592 x 1944 pixels
Video capture resolution (max)	640 x 480 pixels
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	1
Text prediction system type	T9
Multimedia Messaging Service (MMS)	Multimedia Messaging Service (MMS) is a standard way to send messages that include multimedia content to and from a mobile phone over a cellular network
Audio formats supported	AAC, AAC+, AU, eAAC+, M4A, MP3, MP4, WAV, WMA
Image formats supported	BMP, PNG
Talk time (2G)	5 h
Standby time (2G)	408 h
2G standards	EDGE, GPRS
Data network	3G, wcdma
Bluetooth version	2.1+EDR
SIM card capability	Single SIM
Form factor	Slider
Product color	-
Keyboard layout	QWERTY

Weight and Dimensions

Depth	16.85 mm
Width	66.44 mm
Height	74.3 mm
Weight	129 g
