NordicTrack A.C.T. Elite User Manual

7
PART IDENTIFICATION CHART
Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each
drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the
key number is the quantity needed for assembly. Note: If a part is not in the hardware kit, check to see if it
has been preassembled. Extra parts may be included.
M4 x 16mm
Screw (67)–18
M8 x 25mm Flat
Head Screw (68)–6
M10 Locknut
(105)–4
M10 x 50mm Bolt
(100)–4
M8 x 45mm Bolt
(130)–4
M8 Locknut
(111)–4
M8 x 20mm
Screw (61)–12
