M10 Locknut (65)
M8 Locknut (57)
M6 Washer (62)
M4 x 15mm
Screw (58)
M10 x 85mm Button Bolt (51)
M10 x 95mm Button Bolt (53)
M6 x 18mm
Button Screw (55)
M6 x 55mm Button Screw (56)
M4 x 30mm
Screw (63)
M4 x 20mm
Screw (59)
M10 Curved Washer (50)
M6 Nut (43)
M10 x 40mm Button Bolt (69)
M10 x 16mm
Button Screw (54)
M10 x 80mm Button Bolt (52)
M10 x 53mm Button Bolt (49)
M8 x 16mm
Button Bolt (61)
M10 Large Washer (64)
M6 x 37mm Bolt (33)
PART IDENTIFICATION CHART
See the drawings below to identify small parts used in assembly. The number in parentheses by each drawing is
the key number of the part, from the PART LIST near the end of this manual. Note: Some small parts may
have been preassembled. If a part is not in the hardware kit, check to see if it has been preassembled.
