DN-5262 • 10/31/05 — Page 9 of 10
AGENCY LISTINGS AND APPROVALS
See the first page of this catalog sheet for listing agencies
and file numbers. These listings and approvals apply to
the basic AFP-300 or AFP-400 control panel. In some
cases, certain modules may not be listed by certain ap-
proval agencies, or listing may be in process. Consult fac-
tory for latest listing status.
The AFP-300/400 is UL Listed, per Standards 864 (Fire) and
1076 (Burglary). It meets NFPA 72 Local, Auxiliary, Remote
Station, Proprietary, and Emergency Voice/Alarm Fire Sys-
tem Requirements.
SPECIFICATIONS
• Primary input power, 120 VAC, 50/60 Hz, 3.0 Amps.
•
Total
output 24 V power — 6.0 A.*
• Standard Bell circuits (4) per MPS-400 — 2.5 A each.
• Four-wire detector power — 1.25 A.
• Two non-reset regulated power outputs — 1.25 A each.
• Battery charger range: 12 AH - 60 AH.
(Use separate BB-55 cabinet for 55/60 AH batteries.)
• Charge high rate: 29.1 V. Float Rate: 27.6 V.
* Note: The MPS-400 has a total of 6.0 Amps of available power.
This is shared by all internal modules and each MPS-400
circuit.
SYSTEM CAPACITY: AFP-400
• Intelligent Signaling Line Circuits............................... 2
• Intelligent Detectors ................................................198
• Addressable monitor/control modules ..................198
• Programmable internal hardware
and output circuits (four standard) ...........................68
• Programmable software zones ................................ 99
• Special Programming zones ....................................14
• Programmable remote relay/annunciator points.....99
• LCD-80 annunciators per system (observe power) 32
• ACS annunciators per system...10 Address x 64 points
SYSTEM CAPACITY: AFP-300
• Intelligent Signaling Line Circuits............................... 1
• Intelligent Detectors ..................................................99
• Addressable monitor/control modules ....................99
• Programmable internal hardware
and output circuits (four standard) ...........................68
• Programmable software zones ................................ 99
• Special Programming zones ....................................14
• Programmable remote relay/annunciator points.....99
• LCD-80 annunciators per system (observe power) 32
• ACS annunciators per system...10 Address x 64 points
CONTROLS AND INDICATORS
Program Keypad: QWERTY type (keyboard layout).
8 LED indicators: AC Power; Fire Alarm; Pre-Alarm; Secu-
rity Alarm; Supervisory Signal; System Trouble, Disabled
points, Alarm Silenced.
Membrane Switch Controls: Acknowledge/Step; Silence;
Evacuate; System Reset; Lamp Test.
LCD Display: 80 characters (2 x 40) with long-life LED back-
light.
COMPATIBLE DEVICES, EIA-232 Port
PRN-5: 80-column printer.
See DN-6769.
PRN-6: 80-column printer.
See DN-6956.
VS4095/S2: Printer, 40 column, 24 V. Mounted in external
backbox.
See DN-3260; order from Keltron, Inc.
CRT-2: Video display terminal.
See DN-3756.
NAM-232W: Wire peer-to-peer NOTI•FIRE•NET™ net-
work interface module.
See DN-5331.
NAM-232F: Fiber peer-to-peer NOTI•FIRE•NET™ net-
work interface module.
See DN-5331.
COMPATIBLE DEVICES, RS-485 Port
ACS Series: Remote Serial Annunciator/Control systems.
See DN-0524.
FDU-80: Remote LCD display, 80 characters.
See DN-6820.
LCD-80: Remote LCD display, 80 characters.
See DN-3198.
LDM Series: Remote custom graphic driver modules.
See
DN-0551.
ACM-8R: Remote relay module, 8 Form-C relays.
See
DN-3558.
NIB-96: Network Interface Board.
See DN-0597.
RPT-485 Series: Repeater, isolator and/or fiber optic mo-
dem.
See DN-4737.
UDACT: Universal Digital Alarm Communicator Transmit-
ter.
See DN-4867.
UZC-256: Zone Coder, up to 256 programmable codes.
See DN-3404.
COMPATIBLE INTELLIGENT DEVICES
BEAMHK: Heating kit for transmitter/receiver unit of FSB-
200(S) below.
See DN-6985.
BEAMHRK: Heating kit for use with the reflector of FSB-
200(S) below.
See DN-6985.
BEAMLRK: Long-range accessory kit, FSB-200(S) below.
BEAMMRK: Multi-mount kit, FSB-200(S) below.
BEAMSMK: Surface-mount kit, FSB-200(S) below.
FSB-200: Intelligent beam smoke detector.
See DN-6985.
FSB-200S: Intelligent beam smoke detector with integral
sensitivity test.
See DN-6895.
FSI-851: Low-profile ionization detector.
See DN-6934.
FSP-851: Low-profile photoelectric detector.
See DN-6935.
FSP-851T: Low-profile photoelectric detector with 135°F
(57°C) thermal.
See DN-6935.
FST-851: Thermal detector 135°F (57°C).
See DN-6936.
FST-851R: Thermal detector 135°F (57°C) with rate-of-rise.
See DN-6936.
FST-851H: 190°F (88°C) high-temperature thermal detec-
tor.
See DN-6936.
FSD-751PL: Low-flow photo duct detector with housing.
See DN-6955.
FSD-751RPL Low-flow photo duct detector with relay and
housing.
See DN-6955.
FAPT-851: Acclimate Plus™ low-profile multi-sensor de-
tector.
See DN-6937.
FSH-751: HARSH™ Hostile Area Smoke Head.
See
DN-6875.
FSL-751: VIEW® laser photo detector, will replace LPX-
751.
See DN-6886.
LPX-751: Low-profile VIEW® laser photo detector.
See
DN-5306.
