NuTone Flex Series User Manual

4
1
11
Install grille.
LED Fan/Light ONLY:
Snap LED light module
into inside of grille.
Note: On some models,
LED module may
already be installed.
Plug in light module.
Squeeze grille springs
and insert into slots in
blower. Push grille up
against ceiling.
Install blower.
Re-install blower removed in
Step1. Secure blower with 2
screws from parts bag. Plug
blower into black receptacle.
Flex
TM
Series Fan/Light
ONLY: Plug 5-wire plug into
controller module.
Depending upon model - your grille may look different.
1
10
ALL INSTALLATIONS
WIRING DIAGRAM
SWITCH BOX
LIGHT
FAN
2-FUNCTION CONTROL
(purchase separately)
WHITE
BLACK
RED
GROUND
(bare)
WIRING PLATE
120 VAC LINE IN
RECEPTACLE
(FAN)
RECEPTACLE
(LIGHT)
If grille spring
becomes dislodged
from grille - snap it
back into place as
shown.
1100262F
Connect 4-in. round duct.

Pull existing ducting through housing discharge
opening and

tape ducting to duct connector.

Push
connector/ducting back through opening. Engage tabs
and

secure with screw from parts bag.
1
9
Continue with Step 10.
1
2
3
4
TABS
Flex
TM
Series
Fan/Light ONLY
LED
Fan/Light
ONLY
For models 791LEDM
and 791LEDNTM ONLY:
Plug in light  and
LED driver .
1
2
