Specifications > 93
Print accuracy Start: ±2 mm
Paper skew: ±1 mm/100 mm
Image expansion/compression: ±1 mm/100 mm
Interfaces
Universal Serial Bus
(USB)
Network
Parallel Interface (830
only)
USB specification Version 2.0
Connection: USB type B
Cable: USB specification version2.0 (shielded)
Transmission mode: High speed (480Mbps + 0.25% maximum)
10 Base T, 100 Base TX
36 pin Centronics type, receptacle - IEEE 1284-1994
Duty cycle 50,000 pages per month max., 10,000 pages per month average
MTBF 100.000 pages
MTTR 20 minutes
Toner l ife
b
Starter:
CMYK:
2,000 images (750 images used to initially charge image drum)
Replacement:
CMYK: 8,000 images
Image drum life 20,000 Letter/A4 pages average
Belt life 80,000 Letter/A4 pages at 3 pages per job-
Fuser life 100,000 Letter/A4 pages at 3 pages per job-
Power supply 220 to 240VAC @ 50/60 Hz ± 2%
Power consumption Operating: 1350W peak; 570 W av. (25°C)
Idle: 200 W typical (25°C)
Power saving
c
: <15W (C810)<17W (C830)
Operating environment Operating 10 to 32 °C/20 to 80% RH
(optimum 25 °C wet, 2 °C dry)
Off: 0 to 43 °C/10 to 90% RH
(optimum 26.8 °C wet, 2 °C dry)
Print environment 30 to 73% RH @ 10 °C; 30 to 54% RH @ 32 °C
10 to 32 °C @ 30% RH; 10 to 27 °C @ 80% RH
color 17 to 27 °C @ 50 to 0% RH
Noise Levels Operating: Mono/color - less than 54dBa
Standby Mode: less than 37dBa
Power Saving Mode: Background level
a. Exit method is limited by paper size, media weight and paper feed.
b. As defined by ISO/IEC 19798
c. To comply with the requirements of Energy Star, when no data is present for a set period of time,
the printer goes into a power-saving mode. The printer has a “wake-up” feature which, when
initiated from a host device or the operator panel, will revert the printer to its “running” mode.
Specifications subject to change without notice. All trademarks acknowledged.
ITEM SPECIFICATION
