Olympus OFP User Manual

FLUSHING PUMP OFP
13
Regulatory
status
This mark on the product (220-240V model) indicates compliance with Directive
93/42/EEC relating to medical devices, Class IIa. The year of manufacture is
given in the first two digits of the serial number.
0086
End of life
European Economic
Area (EEA)
In accordance with European Directive 2002/96/EC on Waste Electrical and
Electronic Equipment, this symbol indicates that the product must not be
disposed of as unsorted municipal waste, but should be collected separately.
Refer to your local Olympus distributor for return and/or collection systems
available in your country.
Dimensions and
Dimensions Height: 220 mm Width: 270 mm Depth: 350 mm
D
i
m
e
n
s
i
o
n
s
a
n
d
weight
Weight 8kg
Power switch Marking The power switch is marked: l - on, O -off.
Power
Power supply Frequency Fusing Power rating
220-240V~ 50/60Hz 2 x T1A 240VA
P
o
w
e
r
requirements
110-120V~ 50/60Hz 2 x T2A 240VA
Marking: The mark ~ on the product indicates the requirement for an AC power supply.
E
i
t
l
Ambient
temperature
Operational: +10˚Cto+40˚C(+50˚F to +104˚F)
Storage: -40˚Cto+70˚C (-40˚F to +158˚F)
Environmental
c
o
n
d
i
t
i
o
n
s
Relative humidity Maximum: 93% at 40˚C relative non-condensing
c
o
n
d
i
t
i
o
n
s
Atmospheric
pressure
Operational: 70-106 kPa
Storage: 23.5-106 kPa
Fluid ingress Ordinary equipment in accordance with EN IEC 60601-1 and UL 2601--1.
Resistance to
chemicals
The external surfaces of the Olympus OFP are resistant to: 2% aqueous neutral pH detergent, 70% ethyl alcohol,
isopropyl alcohol, water.
Pump type Peristaltic
Pump operation
Water feed: controlled by pneumatic footswitch
Flow rate: variable, controlled from front panel
Flow rate delivery from the pump will depend on the length and type of Olympus EVIS EXERA gastrointestinal
videoscope attached. At minimum setting, the pump will not produce any flow; at maximum setting, the pump will
deliver up to 350 ml/min in free--flow to atmospheric air from the end of the pump irrigation tube and filter.
When attached to an Olympus EVIS EXERA gastrointestinal videoscope, the flow from the distal end will
increase with decreasing endoscope length and the force of the water jet contacting the patient will increase. The
operator must therefore assess the condition of the patient and use clinical judgement to set the flow rate from
the pump to avoid causing patient trauma.
If the pump is connected to any other endoscope or device other than those specified in these instructions, then
damage to the pump or attached device, or injury to to the patient or user may result.
Fluid container The fluid container supplied with the unit has a 1 litre capacity and will withstand steam sterilisation up to 137˚C.
Olympus is continually developing its product range and reserves the right to alter the above s pecification without notice. The
Olympus OFP is manufactured in the UK by KeyMed (Medical & Industrial Equipment) Ltd.
9 TECHNICAL DESCRIPTION
Technical information regarding this product is available on r equest to assist suitably qualified personnel with repairs.
Contact Olympus regarding this information.
10 ENVIRONMENTAL PROTECTION
There are no known risks associated with disposal of irrigation tubing, filter s, or the OFP itself at the end of its working
life.
