13
EN
Preparing the Camera
Inserting the battery
1
2
TG-310: Insert the battery by putting in the ▼ marked
side fi rst, with the C marks toward the battery lock
knob.
TG-610: Insert the battery with the B marks toward
the battery lock knob as shown above.
Damage to the battery exterior (scratches, etc.) may
produce heat or an explosion.
Insert the battery while sliding the battery lock knob in
the direction of the arrow.
2
11
Battery/card/connector cover
Battery/card/connector cover lock
2
11
Battery/card/connector cover
Battery/card/connector cover lock
TG-310 TG-610
Battery lock knob
TG-310 TG-610
Battery lock knob
3
When removing the battery or card, be sure to turn off
the camera before opening or closing the battery/
card/connector cover.
When using the camera, be sure to close and lock
the battery/card/connector cover.
Slide the battery lock knob in the direction of the
arrow to unlock, and then remove the battery.
Charging the battery and setting up
using the supplied CD
Connect the camera to the computer to charge the battery
and use the supplied CD for setup.
User registration using the supplied CD and
installation of ib computer software is available on
Windows computers only.
The camera battery can be charged while the camera is
connected to a computer.
The indicator lamp lights during charging and turns
off when charging is complete.
Charging takes up to 3 hours.
If the indicator lamp does not light, the camera is not
correctly connected or the battery, camera, computer,
or USB cable may not be functioning as expected.
●
1
12
1
12
To Next Page
