Names of Parts
Camera unit
1
2
3
7
4
5
6
10
8
9
12
7
11
10
8
9
11
TG-610
1 Battery/card/connector
cover lock....................p. 13
2 Strap eyelet ..................p. 10
3 HDMI micro connector
....................................p. 52
4 Battery lock knob ..........p. 13
5 Multi-connector
..................p. 14, 16, 52, 56
6 Battery/card/connector cover
............p. 13, 14, 16, 52, 70
7 Microphone ...................p. 45
8 Self-timer lamp/
LED illuminator* ....p. 36, 38
9 Flash .............................p. 34
10
Lens ..............................p. 65
11
Tripod socket
12
Speaker
* TG-610 only
