Recording with an external microphone
20
EN
Recording with an external microphone
You can record audio input using an external microphone or other device connected to
the voice recorder’s MIC jack. Do not plug or unplug devices into voice recorder jacks while
recording.
1
Connect an external microphone
to the voice recorder’s MIC jack.
To MIC
jack
Example: TP8 telephone pickup
microphone (optional)
2
Press the REC ( s) button to start
recording.
TIP
• When using the phone micr
ophone
(Telephone pickup TP8), set
[RecScene] to [Telephone Rec]. This
allows you to record conversations on
mobile and landline telephones clearly
(☞P.23).
• See “Accessories (optional)”
(☞P.56) for the compatible external
microphones.
NOTE
• C
onnecting an external microphone to
the voice recorder’s MIC jack disables
the built-in microphone.
• Microphones with plug-in power
supplies can be used.
• When [Rec Mode] is set to stereo,
recording with an external mono
microphone records on the left channel
only (☞P.38).
• When [Rec Mode] is set to mono,
only the input from the left channel
microphone is recorded when using an
external stereo microphone (☞P.38).
Recording with an external microphone

Olympus VN-722PC Specifications

General

Product color	Black, Silver
Impedance	8 Ω
Recording modes	-
Maximum recording time	1600 h
Audio formats supported	MP3, WMA
Internal memory	4096 MB
Built-in display	Yes
Loudspeaker diameter	28 mm
Number of built-in speakers	1
Interface	USB
FM radio	No
Media types supported	Internal memory & flash card
Compatible memory cards	MicroSD (TransFlash)
Built-in memory capacity	32 GB
Battery life (max)	100 h
Battery technology	Nickel-Metal Hydride (NiMH)
Compatible battery sizes	AAA
Operating temperature (T-T)	0 - 42 °C

Weight and Dimensions

Depth	16.8 mm
Width	39 mm
Height	108 mm
Weight	71 g
