1716
Precautions: Be Sure to Read the Following
Submergence
Do not put the lens with
its contacts facing down.
Abrupt temperature
changes
Do not drop
Organic solvents
Magnetism
Moth repellents
Too much pressure
Lens cleaning
Excessive moisture
Do not touch the lens.
Do not touch the
contacts.
Do not view the sun
through the lens.
Cap the lens when it is
not used.
Do not leave the lens without the
cap. If solar light is converged
through the lens, a fire may result.
Do not point the camera lens at the
sun. Sunlight will converge in the lens
and focus inside the camera, possi-
bly causing a malfunction or fire.
Working temperature
range
Handling Precautions
Storage Precautions
Warnings: Safety Precautions
Lens cleaning tissue or
soft cloth
Focus Limit Switch
-
8m
8
-
2.5m
-
2.5m
This switch limits the autofocus range to speed up focusing in each
range.
Select the optimum mode according to the shooting distance.
Close-up shooting : Autofocus is performed between 8 meters
(26.6 ft) and 2.5 meters (8.3 ft).
Normal shooting : Autofocus is performed from (infinity) to
2.5 meters (8.3 ft).
Distant shooting : Autofocus is performed from (infinity) to
8 meters (26.6 ft).
Focus Stop Buttons
By holding down one of the focus stop buttons, you
can deactivate autofocus operation and fix focus at the
point where the button was pressed.
•Four buttons are provided. All have the same effect.
Shooting Cautions
Be sure to attach the hood when shooting against the light.
•When two or more filters are used or a thick filter is used, part of the picture may be cut off or
obscured.
Attaching Lens Cap LC-140

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Olympus Zuiko DIGITAL ED and is the answer not in the manual?

Olympus Zuiko DIGITAL ED Specifications

Lens Specifications IconLens Specifications
mountFour Thirds mount
focal distance90-250 mm
max aperturef2.8
image angle14°-5.0°
lens configuration17 elements in 12 groups
iris controlf2.8 to f22
shooting range2.5 m (8.3 ft) to ∞ (infinity)
focus adjustmentAF/MF switching
Weight and Dimensions IconWeight and Dimensions
weight3250 g (114.6 oz)
dimensionsMax. dia. ø123 mm (4.8 in) x Overall length 276 mm (10.9 in)
filter mount thread diameter105 mm (4.2 in)
