7. Parameter List
Parameter ListParameter List
Parameter List
Code Function name Monitoring and setting items
Units
AA101 Main speed input source selection, 1st-motor
01 (Setting by Terminal [Ai1]) /02 (Setting by Terminal [Ai2]) /03 (Setting by Terminal [Ai3]) /04
(Setting by Terminal [Ai4]) /05 (Setting by Terminal [Ai5]) /06 (Setting by Terminal [Ai6]) /07 (Setting
by parameter) /08 (Setting by RS485) /09 (Option-1) /10 (Option-2) /11 (Option-3) /12 (Pulse train
input(internal)) /13 (Pulse train input(Option)) /14 (Setting by EzSQ) /15 (PID function) /16 (Volume on
keypad)
―
AA102 Sub frequency input source selection, 1st-motor
00 (Disable) /01 (Setting by Terminal [Ai1]) /02 (Setting by Terminal [Ai2]) /03 (Setting by Terminal
[Ai3]) /04 (Setting by Terminal [Ai4]) /05 (Setting by Terminal [Ai5]) /06 (Setting by Terminal [Ai6])
/07 (Setting by parameter) /08 (Setting by RS485) 09 (Option-1) /10 (Option-2) /11 (Option-3) /12 (Pulse
train input(internal)) /13 (Pulse train input(Option)) /14 (Setting by EzSQ) /15 (PID function) /16
(Volume on keypad)"
―
AA104 Sub speed setting, 1st-motor 0.00～590.00
Hz
AA105
Calculation symbol selection for Speed reference, 1st-
motor
00 (Disable) /01 (Addition(ADD)) /02 (Subtraction(SUB)) /03 (Multiplication(MUL))
―
AA106 Add frequency setting, 1st-motor −590.00～＋590.00（Hz）
0.01Hz
AA111 Run-command input source selection, 1st-motor
00 (Terminal [FW]/[RV]) /01 (3-wire) /02 (RUN key on keypad) /03 (Setting by RS485) /04 (Option-1) /05
(Option-2) /06 (Option-3)
―
AA114 RUN-direction restriction, 1st-motor 00 (Disable) /01 (Enable only Forward rotation) /02 (Enable only Reverse rotation)
―
AA115 STOP mode selection, 1st-motor 00 (Deceleration until stop) /01 (Free-run stop)
―
AA-12 RUN-key of keypad Rotation Direction, 1st-motor 00 (Forward) /01 (Reverse)
―
AA121 Control mode selection, 1st-motor
IM control: 00 (VF control (Constant torque)) /01 (VF control (Reduced torque)) /02 (VF control (Free-
V/f)) /03 (Constant torque with Automatic- trq boost)) /04 (VF control with encoder (Constant torque))
/05 (VF control with encoder (Reduced torque)) /06 (VF control with encoder (Free-V/f)) /07 (VF control
with PG (Constant torque with Automatc-trq boost)) /08 (Sensorless vector control) /09（0Hz Sensorless
vector control）/10（Vector control with encoder）
SM/PMM control: 11 (Synchronous start up for smart sensorless vector control）/12（IVMS start up for
smart sensorless vector control）
0
AA123 Vector control mode selection, 1st-motor
00 (Speed/Torque control mode) /01 (Pulse train position control) /02 (Position control) /03 (High-
resolution position control)
―
AA-13 STOP-key enable at RUN-command from terminal, 1st-motor 00 (Disable) /01 (Enable) /02 (Enable at only trip reset)
―
AA201 Main speed input source selection, 2nd-motor same to AA101
―
AA202 Sub speed input source selection, 2nd-motor same to AA102
―
AA204 Sub speed setting, 2nd-motor same to AA104
―
AA205 Calculation symbol selection for Speed reference, 2nd-motor same to AA105
―
AA206 Add frequency setting, 2nd-motor same to AA106
―
AA211 Run-command input source selection, 2nd-motor same to AA111
―
AA214 RUN-direction restriction, 1st-motor same to AA114
―
AA215 STOP mode selection, 1st-motor same to AA115
―
AA221 Control mode selection, 2nd-motor Same as AA121, except 12
0
AA223 Vector control mode selection, 2nd-motor same to AA123
―
Ab-01 Frequency conversion gain 0.01～100.00
0.01
Ab-03 Multispeed operation selection 00 (Binary (16-speeds)) /01 (Bit (8-speeds))
―
Ab-11 Multispeed-1 setting 0.00～590.00（Hz）
0.01Hz
Ab110 Multispeed-0 setting, 1st-motor 0.00～590.00（Hz）
0.01Hz
Ab-12 Multispeed-2 setting 0.00～590.00（Hz）
0.01Hz
Ab-13 Multispeed-3 setting 0.00～590.00（Hz）
0.01Hz
Ab-14 Multispeed-4 setting 0.00～590.00（Hz）
0.01Hz
Ab-15 Multispeed-5 setting 0.00～590.00（Hz）
0.01Hz
Ab-16 Multispeed-6 setting 0.00～590.00（Hz）
0.01Hz
Ab-17 Multispeed-7 setting 0.00～590.00（Hz）
0.01Hz
Ab-18 Multispeed-8 setting 0.00～590.00（Hz）
0.01Hz
Ab-19 Multispeed-9 setting 0.00～590.00（Hz）
0.01Hz
Ab-20 Multispeed-10 setting 0.00～590.00（Hz）
0.01Hz
Ab-21 Multispeed-11 setting 0.00～590.00（Hz）
0.01Hz
Ab210 Multispeed-0 setting, 2nd-motor Same as Ab110
0.01Hz
Ab-22 Multispeed-12 setting 0.00～590.00（Hz）
0.01Hz
Ab-23 Multispeed-13 setting 0.00～590.00（Hz）
0.01Hz
Ab-24 Multispeed-14 setting 0.00～590.00（Hz）
0.01Hz
Ab-25 Multispeed-15 setting 0.00～590.00（Hz）
0.01Hz
AC-01 Acceleration/ Deceleration time input selection
00 (Setting by parameter) /01 (Setting from Option-1) /02 (Setting from Option-2) /02 (Setting from
Option-3) /04 (Setting by programing function)
―
AC-02 Acceleration/ Deceleration selection 00 (Common setting) /01 (Multi stage Acceleration/ Deceleration) ―
AC-03 Acceleration curve selection
00 (Liner Acceleration) /01 (S-curve Acceleration) /02 (U-curve Acceleration) /03 (Reverse U-curve
Acceleration) /04 (Eleveter S-curve Acceleration)
―
AC-04 Deceleration curve selection
00 (Liner Acceleration) /01 (S-curve Acceleration) /02 (U-curve Acceleration) /03 (Reverse U-curve
Acceleration) /04 (Eleveter S-curve Acceleration)
―
AC-05 Acceleration curve constant setting 1～10
―
AC-06 Deceleration curve constant setting 1～10
―
AC-08 EL-S-curve ratio @start of acceleration 0～100
1%
AC-09 EL-S-curve ratio @end of acceleration 0～100
1%
AC-10 EL-S-curve ratio @start of deceleration 0～100
1%
AC-11 EL-S-curve ratio @start of deceleration 0～100
1%
AC115 Select method to switch to Accel2/Decel2 Profile, 1st-motor
00 (Switching by [2CH] terminal) /01 (Switching by setting) /02 (Switching only when rotation is
reversed)
―
AC116 Accel1 to Accel2 Frequency transition point, 1st-motor 0.00～590.00（Hz）
0.01Hz
AC117 Decel1 to Decel2 Frequency transition point, 1st-motor 0.00～590.00（Hz）
0.01Hz
AC120 Acceleration time setting 1, 1st-motor 0.00～3600.00（s）
0.01s
AC122 Deceleration time setting 1, 1st-motor 0.00～3600.00（s）
0.01s
AC124 Acceleration time setting 1, 1st-motor 0.00～3600.00（s）
0.01s
AC126 Deceleration time setting 1, 1st-motor 0.00～3600.00（s）
0.01s
AC215 Select method to switch to Accel2/Decel2 Profile, 2nd-motor
00 (Switching by [2CH] terminal) /01 (Switching by setting) /02 (Switching only when rotation is
reversed)
―
