Omron 3G3RX2-A2 Series Quick Start Guide

1
4
3
G
3
R
X
2
S
e
r
i
e
s
Hig
h
-
f
unc
t
ion
G
e
neral
-
p
ur
p
ose
I
n
verter
Us
e
r
’s
Manu
a
l
(I620)
2. Specifications
SpecificationsSpecifications
Specifications
2.1. Upon receipt
Upon receiptUpon receipt
Upon receipt
Please perform the following task after receiving the drive:
• Inspect the driver for damage. If the drive appears damage upon receipt, contact your supplier.
• Verify the receipt of the correct model by checking the information on the nameplate. If you have received the
wrong model contact your supplier.
• Refer to the User’s Manual for detailed information about the product and functions.
Basic specifications and EMC filter
Type ND(150% overload for 60s) LD(120% overload for 60s) VLD(110% overload for 60s)
Voltage 3G3RX2-
Max Motor
(KW)
Rated current
(A)
Max Motor
(KW)
Rated current
(A)
Max Motor
(KW)
Rated current
(A)
EMC filter
A2004 0.4 3.2 0.75 3.7 0.75 4.4
A2007 0.75 5 1.5 6.3 1.5 8
A2015 1.5 8 2.2 9.4 2.2 10.4 AX-FIR2018-RE
A2022 2.2 11 3.7 12 3.7 15.6
A2037 3.7 17.5 5.5 19.6 5.5 22.8
A2055 5.5 25 7.5 30 7.5 33
A2075 7.5 32 11 40 11 46 AX-FIR2053-RE
3 x 200 V
A2110 11 46 15 56 15 60
A2150 15 64 18.5 73 18.5 80
A2185 18.5 76 22 85 22 93 AX-FIR2110-RE
A2220 22 95 30 113 30 124
A2300 30 122 37 140 37 153 AX-FIR2145-RE
A2370 37 146 45 169 45 185
A2450 45 182 55 210 55 229 AX-FIR3250-RE
A2550 55 220 75 270 75 295 AX-FIR3320-RE
A4007 0.75 2.5 1.5 3.1 1.5 4.1
A4015 1.5 4 2.2 4.8 2.2 5.4 AX-FIR3010-RE
A4022 2.2 5.5 3.7 6.7 3.7 8.3
A4040 3.7 9.2 5.5 11.1 5.5 12.6
A4055 5.5 14.8 7.5 16 7.5 17.5
A4075 7.5 19 11 22 11 25 AX-FIR3030-RE
A4110 11 25 15 29 15 31
