1-5 C-series–CV-series System Compatibility
The following table shows when C-series Units can be used and when CV -series
Units must be used. Any C-series Unit or Peripheral Device not listed in this table
cannot be used with the CV-series PCs.
Unit C Series CV Series Remarks
CPU Rack CPU No Yes CV500-CPU01-EV1, CV1000-CPU01-EV1,
CV2000-CPU01-EV1, CVM1-CPU01-EV2,
CVM1-CPU11-EV2, and CVM1-CPU21-EV2
Power Supply No Yes CV500-PS221, CV500-PS21 1, and
CVM1-PA208
CPU Backplane No Yes CV500-BC031, CV500-BC051, CV500-BC101,
CVM1-BC103, and CVM1-BC053
I/O Control Unit No Yes CV500-ICj01
Expansion CPU Backplane No Yes CV500-BI111
Expansion I/O Backplane No Yes CV500-BI042, CV500-BI062, CV500-BI112,
CVM1-BI114, and CVM1-BI064 (C500
Expansion I/O Racks can be used with certain
limitations.)
16-/32-/64-point I/O Units Yes Yes ---
Special I/O Units Yes Yes Applicable Units include Analog Input, Analog
Output, High-speed Counter, PID, Position
Control, Magnetic Card, ASCII, ID Sensor , and
Ladder Program I/O Units (The C500-ASC03
cannot be used.)
BASIC Unit No Yes CV500-BSCj1
Personal Computer Unit No Yes CV500-VP213-E/217-E/223-E/227-E
Temperature Control Data Link Unit No Yes CV500-TDL21
Link
S
SYSMAC NET No Yes CV500-SNT31
Systems
SYSMAC LINK No Yes CV500-SLK11 and CV500-SLK21
Host Link Unit No Yes CV500-LK201
Ethernet Unit No Yes CV500-ETN01
Remote I/O
S
SYSMAC BUS Units Yes Yes ---
Systems
SYSMAC BUS/2 No Yes CV500-RM211/221 and CV500-RT211/221
Peripheral
Devices
CV Support Software No Yes
(See note.)
CV500-ZS3AT1-EV2 (3 1/2” floppy disks) and
CV500-ZS5AT1-EV2 (5 1/4” floppy disks) for
IBM PC/AT compatible
SYSMAC Support
Software (SSS)
Yes Yes
(See note.)
C500-ZL3AT1-E (3.5” floppy disks) for IBM
PC/AT compatible
Graphic Programming
Console
Yes (Main
unit only)
Yes
(System
Cassette)
(See note.)
GPC: 3G2C5-GPC03-E
System Cassette: CV500-MP311-E
Programming Console No Yes
(See note.)
CVM1-PRS21-EV1 (set)
Note The CVSS does not support new instructions added for version-2 CVM1 PCs.
The SSS does not support SFC programming (CV500, CV1000, and CV2000).
New instructions added for version-2 CVM1 PCs are also supported by ver-
sion-1
CV -series Programming Consoles.
C-series–CV-series System Compatibility Section 1-5
