A Appendices
A - 12
Digital Temperature Controllers (Simple Type) User’s Manual (H211)
A-5 Parameter Operation Lists
A-5-1 Operation Level
Parameters Characters Setting (monitor) value Display Default Unit
Process Value Temperature: According to indication range for each
sensor.
Analog: Scaling lower limit
−5% FS to Scaling upper limit +5% FS
EU
Set Point SP lower limit to SP upper limit 0 EU
Multi-SP Set Point
Selection
m-sp 0 to 7 0 None
Set Point During SP
Ramp
sp-m SP lower limit to SP upper limit EU
Heater Current 1 Value
Monitor
ct1 0.0 to 55.0 A
Leakage Current 1
Monitor
lcr1 0.0 to 55.0 A
RUN/STOP r-s RUN/STOP run, stop Run None
Alarm Value 1 al-1 All alarms except for MV absolute-value upper-limit or
lower-limit alarms: −1,999 to 9,999
0EU
MV absolute-value upper-limit or lower-limit alarms:
−199.9 to 999.9
0.0 %
Alarm Value Upper Limit 1 al1h −1,999 to 9,999 0 EU
Alarm Value Lower Limit 1 al1l −1,999 to 9,999 0 EU
Alarm Value 2 al-2 All alarms except for MV absolute-value upper-limit or
lower-limit alarms: −1,999 to 9,999
0EU
MV absolute-value upper-limit or lower-limit alarms:
−199.9 to 999.9
0.0 %
Alarm Value Upper Limit 2 al2h −1,999 to 9,999 0 EU
Alarm Value Lower Limit 2 al2l −1,999 to 9,999 0 EU
Alarm Value 3 al-3 All alarms except for MV absolute-value upper-limit or
lower-limit alarms: −1,999 to 9,999
0EU
MV absolute-value upper-limit or lower-limit alarms:
−199.9 to 999.9
0.0 %
Alarm Value Upper Limit 3 al3h −1,999 to 9,999 0 EU
Alarm Value Lower Limit 3 al3l −1,999 to 9,999 0 EU
Alarm Value 4 al-4 All alarms except for MV absolute-value upper-limit or
lower-limit alarms: −1,999 to 9,999
0EU
MV absolute-value upper-limit or lower-limit alarms:
−199.9 to 999.9
0.0 %
Alarm Value Upper Limit 4 al4h −1,999 to 9,999 0 EU
Alarm Value Lower Limit 4 al4l −1,999 to 9,999 0 EU
MV Monitor (Heating) o −5.0 to 105.5 (standard)
0.0 to 105.0 (heating/cooling)
%
MV Monitor (Cooling) c-o 0.0 to 105.0 %
To Next Page
