LBA Level lbal Temperature input: 0.1 to 999.9 8.0 °C or °F
Analog input: 0.01 to 99.99 10.00 %FS
LBA Band lbab Temperature input: 0.0 to 999.9 3.0 °C or °F
Analog input: 0.00 to 99.99 0.20 %FS
Control Output 1
Assignment
out1
Relay Output or Voltage Output (for Driving SSR)
*2
ONone
NONE: No assignment none
O: Control output (heating) o
C-O: Control output (cooling) c-o
ALM1: Alarm 1 alm1
ALM2: Alarm 2 alm2
ALM3: Alarm 3 alm3
ALM4: Alarm 4 alm4
HA: Heater alarm (HB + HS)
ha
HB: Heater burnout alarm (HB)
hb
HS: Heater short alarm (HS)
hs
S.ERR: Input error s.err
RS.ER: Remote SP input error
*1
rs.er
P.END: Program End output
*1
p.end
RUN: RUN output run
ALM: Integrated alarm alm
Current Output
*2
NONE: Not assigned. none
O: Control output (heating) o
C-O: Control output (cooling) c-o
Control Output 2
Assignment
out2 Same as the Control Output 1 Assignment
parameter.
Same as the
Control
Output 1
Assignment
parameter.
NONE None
Auxiliary Output 1
Assignment
sub1 NONE: No assignment none ALM1
*Controllers
without HB
and HS
alarm
detection:
HA
None
O: Control output (heating) o
C-O: Control output (cooling) c-o
ALM1: Alarm 1 alm1
ALM2: Alarm 2 alm2
ALM3: Alarm 3 alm3
ALM4: Alarm 4 alm4
HA: Heater alarm (HB + HS)
ha
HB: Heater burnout alarm (HB)
hb
HS: Heater short alarm (HS)
hs
S.ERR: Input error s.err
RS.ER: RSP input error
*1
rs.er
P.END: Program end output
*1
p.end
RUN: RUN output run
ALM: Integrated alarm alm
Auxiliary Output 2
Assignment
sub2 Same as the Auxiliary Output 1 Assignment
parameter.
Same as the
Auxiliary
Output 1
Assignment
parameter.
ALM2 None
Integrated Alarm
Assignment
alma 0 to 255
Alarm 1: +1
Alarm 2: +2
Alarm 3: +4
Alarm 4: +8
HB alarm: +16
HS alarm: +32
Input error: +64
RSP input error: +128
*1
49 None
Parameters Characters Setting (monitor) value Display Default Unit
