3
G9SA
Specifications
Ratings
Power Input
* When an Expansion Unit is connected, the power consumption is increased by 2 VA/2 W max.
Inputs
* When an Expansion Unit is connected, the input current is increased by 30 mA max.
Contacts
Characteristics
*1. The contact resistance was measured with 1 A at 5 VDC using the voltage-drop method.
*2. Not Including bounce time.
*3. The response time is the time it takes for the main contact to open after the input is turned OFF. Includes bounce time.
*4. The insulation resistance was measured with 500 VDC at the same places that the dielectric strength was checked.
*5. The durability is for an ambient temperature of 15 to 35°C and an ambient humidity of 25% to 75%.
*6. Weight shown is for 24-VAC/VDC type. For 100 to 240-VAC type, add approximately 20 g.
Item Model G9SA-301/TH301 G9SA-501 G9SA-321-T@
Power supply voltage
24 VAC/VDC:24 VAC, 50/60 Hz, or 24 VDC
100 to 240 VAC:100 to 240 VAC, 50/60 Hz
Operating voltage range 85% to 110% of rated power supply voltage
Power consumption *
24 VAC/VDC: 1.8 VA/1.7 W max.
100 to 240 VAC: 9 VA max.
24 VAC/VDC: 2.8 VA/2.6 W max.
100 to 240 VAC: 11 VA max.
24 VAC/VDC: 3.5 VA/3.3 W max.
100 to 240 VAC: 12.5 VA max.
Item Model G9SA-301/321-T@/TH301 G9SA-501
Input current * 40 mA max. 60 mA max.
Model G9SA-301/501/321-T@/TH301/EX301/EX031-T@
Item Load Resistive load
Rated load
250 VAC, 5 A
30 VDC, 5 A
Rated carry current 5 A
Item Model G9SA-301/TH301 G9SA-501/321-T@ G9SA-EX301/EX031-T@
Contact resistance *1 100 mΩ
Operating time *2 30 ms max.
Response time *3 10 ms max.
Insulation resistance *4 100 MΩ min. (at 500 VDC)
Dielectric
strength
Between different outputs
2,500 VAC, 50/60 Hz for 1 min
Between inputs and outputs
Between power inputs and outputs
Between power inputs and other
inputs (only for 100 to 240-V models)
Vibration resistance 10 to 55 to 10 Hz, 0.375-mm single amplitude (0.75-mm double amplitude)
Shock
resistance
Destruction 300 m/s
2
Malfunction 100 m/s
2
Durability *5
Mechanical 5,000,000 operations min. (at approx. 7,200 operations/hr)
Electrical 100,000 operations min. (at approx. 1,800 operations/hr)
Failure rate (P Level) (reference value) 5 VDC, 1 mA
Ambient operating temperature −25 to 55°C (with no icing or condensation)
Ambient operating humidity 35% to 85%
Terminal tightening torque 0.98 N·m
Weight *6 Approx. 210 g Approx. 270 g Approx. 130 g
