H5CR H5CR
14
■ EXAMPLES
Changing the Set Value
Run Mode
To change the set value from 3 hr 5 min to 4 hr 5 min, press
the 3 key so that the number 4 appears in the hour's place.
• Pressing keys 1 through 4 increments the corresponding
column by 1.
• The columns can be changed in any order, but the output will
be turned ON if the set value is less than the present value.
• Nonsignificant zeros are suppressed on the set value display.
Note: Read
Changing Set Values
in the
Precautions
section
before changing the timer set value during operation.
Setting Mode
Changing Settings in the Set Mode
1. Press the MODE key to switch from run mode to set mode.
• The timer will continue operation according to existing
settings when switched from run mode to set mode during
operation.
• The MODE key will be locked if the key protection function
is enabled.
• Settings changed in the set mode do not take effect until
run mode is entered. Because the operating conditions will
change once this occurs, always use the RESET key or a
reset input to reset operation.
3. To change the selected item,
• Press the MODE key until the desired item appears.
• Change the item setting by pressing keys 1 through 4.
(Press the DISPLAY key to switch back from set mode to
run mode.)
2. Press the MODE key to scroll successively through the items
that can be set.
To Next Page
