Omron H5S Series User Manual

H5S
11
■ Accessories (Order Separately)
■ Track Mounting Accessories (Order Separately)
Protective Cover
Y92A-72C
DIN Track Mounting
Base
Y92F-90
Note: The DIN Track Mounting Base can be
used only with the surface mounting
models (H5S-@FA@/-@FB@).
Large Terminal Covers
Y92A-72H (two per set)
Note: The Large Terminal Cover can be
used only with the surface mounting
models (H5S-@FA@/-@FB@).
1
35
±0.3
7.3
±0.15
27
±0.15
4.5
15 25 25
10
15 (5) *
10
25 25
* The numbers in parentheses ( ) are dimensions for the PFP-50N
1,000 (500) *
Mounting Track
PFP-100N
PFP-50N
15 25 25
1,000
4.5
25 25 15
10
1
242735
±0.3
16
1.5
29.2
10
PFP-100N2
4.8
1.3
35.5 35.3
1.8
1
1.8
10
6.2
M4 spring washer
50
11.5
M4 × 8
pan-head
screw
10
End Plate
PFP-M
5
16
12
44.3
34.8
16.5
Spacer
PFP-S
