H5S
3
Ordering Information
■ List of Models
■ Accessories (Order Separately)
Specifications
■ Ratings
Note: 1. Do not use inverter output as a power supply. For details, refer to Precautions for Safe Use, item 24, on page 12.
2. The capacity is 15 A per circuit, but derating of the total current for two circuits is required as shown below depending on the ambient
temperature.
Control cycle Number of outputs Mounting method Supply voltage Models
Weekly 2 circuits Flush mounting 100 to 240 VAC H5S-WB2
24 VDC H5S-WB2D
Surface mounting/
track mounting
100 to 240 VAC H5S-WFB2
24 VDC H5S-WFB2D
Yearly 2 circuits Flush mounting 100 to 240 VAC H5S-YB2-X
24 VDC H5S-YB2D-X
Surface mounting/
track mounting
100 to 240 VAC H5S-YFB2-X
24 VDC H5S-YFB2D-X
4 circuits Flush mounting 100 to 240 VAC H5S-YB4-X
24 VDC H5S-YB4D-X
Surface mounting/
track mounting
100 to 240 VAC H5S-YFB4-X
24 VDC H5S-YFB4D-X
Name Model
Protective Cover Y92A-72C
Track Mounting Base Y92F-90
Large Terminal Cover (in pairs) Y92A-72H
Item Weekly 2-circuit Models
(H5S-W@2)
Yearly 2-circuit Models
(H5S-Y@2)
Yearly 4-circuit Models
(H5S-Y@4)
Rated supply voltage 100 to 240 VAC (50/60 Hz), 24 VDC (See note 1.)
Operating voltage range AC: 85% to 110% rated supply voltage
DC: 85% to 120% rated supply voltage
Power consumption Approx. 2.9 VA at 264 VAC 60 Hz
Approx. 0.8 W at 28.8 VDC
Approx. 3.2 VA at 264 VAC 60 Hz
Approx. 0.9 W at 28.8 VDC
Approx. 3.5 VA at 264 VAC 60 Hz
Approx. 1.0 W at 28.8 VDC
Control
outputs
Number of circuits SPST-NO × 2 circuits SPST-NO × 4 circuits
Circuits Power supply circuit and other (no-voltage) circuit
Capacity Resistive load
(cosφ = 1)
15 A at 250 VAC (See note 2.) 3 A at 250 VAC
Inductive load 10 A at 250 VAC (cosφ = 0.7) 2 A at 250 VAC (cosφ = 0.4)
Ambient operating temperature −10 to 55°C (with no icing or condensation)
Ambient operating humidity 25 to 85%
Storage temperature −25 to 65°C (with no icing or condensation)
Case color Light gray (Munsell 5Y7/1)
40
30
20
10
0
10 0 20 40 50 55 60 80
Ambient temperature (°C)
Total current (A)
