Omron H7CX Series User Manual

32
H7CXH7CX
Dimensions
Note: All units are in millimeters unless otherwise indicated.
■
Counter (without Flush Mounting Adapter)
100
6
48×48
44.8×44.8
64
6
44.8×44.8
48×48
72.5
14.4
6
48×48
44.8×44.8
Screw-terminal Models with External Power Supplies (Flush Mounting)
Note: M3.5 terminal screw (effective length: 6 mm)
Screw-terminal Models without External Power Supplies (Flush Mounting)
Note: M3.5 terminal screw (effective length: 6 mm)
11-pin Socket Models (Flush Mounting/Surface Mounting)
 H7CX-A  H7CX-AW  H7CX-AU
 H7CX-AS  H7CX-AWS  H7CX-AUD1
 H7CX-A4  H7CX-A4W  H7CX-AUSD1
 H7CX-A4S  H7CX-AWD1
 H7CX-AWSD1
 H7CX-AD  H7CX-AWSD
 H7CX-ASD  H7CX-A4WSD
 H7CX-A4D
 H7CX-A4SD
 H7CX-A11  H7CX-A114
 H7CX-A11S  H7CX-A114S
 H7CX-A11D1  H7CX-A114D1
 H7CX-A11SD1
