SDGSDGSKNOW YOUR UNIT
10
Main unit
Grip electrodes
Extremely low-level
electrical current is sent
from here during
the measurement.
On/Off button
Turns the power
on and off.
Battery cover
Set button
Sets the personal number
and the personal data.
Down/Up button
Sets the numerical values for personal information
including height, weight, age and gender. This button
is also used to set the personal numbers from 1 to 9.
Display
Displays the set values and
the measured results.
Start button
Press the button and
the measurement starts.
Grip electrodes
HBF-306C Rev D 2/7/06 9:14 AM Page 10
