S8VS
25
Mounting Brackets
Note: Brackets cannot be used for 480-W models.
* Two required to mount a 240-W model.
Name Model
Side-mounting Bracket (for 15- and 30-W models) S82Y-VS30P
Side-mounting Bracket (for 60-, 90-, and 120-W models) S82Y-VS10S
Side-mounting Bracket (for 180-W models) S82Y-VS15S
Side-mounting Bracket (for 240-W models) S82Y-VS20S
Front-mounting Bracket (for 60-, 90-, 120-, 180-, and 240-W models) * S82Y-VS10F
Type Model Dimensions Appearance
Side-mounting Bracket
(For 15-, 30-W models)
S82Y-VS30P
Side-mounting Bracket
(For 60-, 90-, 120-W
models)
S82Y-VS10S
Side-mounting Bracket
(For 180-W models)
S82Y-VS15S
Side-mounting Bracket
(For 240-W models)
S82Y-VS20S
Front-mounting Bracket
(For 60-, 90-, 120-, 180-,
and 240-W models)
S82Y-VS10F
7.1
3.5
0.5
15
15
93.6
109.4
±0.1
85.4
22.5
34
28
t = 0.8
15
3.5 dia.
35
64
t = 2.0
80
60
±0.1
55
±0.1
13
4.5 dia.
±0.1
Left-side mounting Right-side mounting
t = 2.0
89
78
55±0.1
47.5
4.5 dia.±0.1
80
60±0.1
Left-side mounting
*Right-side mounting also possible.
60
±0.1
55
±0.1
13
80
78
114
4.5 dia.
±0.1
t = 2.0
60
Left-side mounting
*Right-side mounting also possible.
41
35
±0.1
40
50
4.5 dia.±0.1
35
25
10
7.3
(For 60-, 90-, 120-,
180-W types)
(For 240-W type)
*Use two S82Y-VS10F
brackets for the 240-W type.
