Page #65 background image
Appendix AStandard Models
59
Special Units
Name Specifications Model number Standards
Analog Timer Unit Settings: 0.1 s to 10 min (one cable, C4K–CN502, in-
cluded)
C4K–TM –––
Analog Timer External
Connector
2–m cable and connector C4K–CN223 –––
Analog Input Unit 1 input; input ranges: 4 to 20 mA, 1 to 5 V C1K–AD –––
4 inputs; input ranges: 4 to 20 mA, 1 to 5 V C4K–AD –––
Analog Output Unit 1 output; output ranges: 4 to 20 mA, 1 to 5 V C1K–DA –––
Host Link Unit RS–232C C20/C20K/C28K/C40K/C60K 3G2C7–LK201–EV1 –––
RS–422 3G2C7–LK202–EV1 –––
I/O Link Unit APF/PCF C20–LK011–P –––
PCF C20–LK011 –––
I/O Connecting Cable For horizontal mounting; cable length: 5 cm
(for maintenance)
C20P–CN501 –––
For vertical mounting; cable length: 40 cm
(for maintenance)
C20P–CN411 –––
I/O Connecting Cable For horizontal mounting; connects to
C4K I/O Units, Analog Timer Unit, or
A l I/O U it (f i t )
Cable length:
5 cm
C4K–CN501 –––
Analog I/O Units (for maintenance)
Cable length:
50 cm
C4K–CN512 –––
Cable length:
1 m
C4K–CN122 –––
I/O Link Connecting
Cable
Cable length: 70 cm; for I/O Link Units only C20P–CN711 –––
EPROM 2764 ROM–H –––
Battery Set Built into CPU (same for all C–Series PCs) 3G2A9–BAT08 –––
Relay 24–VDC contact relay G6B–1174P–FD–US U, C
24–VDC transistor relay G3SD–Z01P–PD–US U, C
24–VDC triac relay G3S–201PL–PD–US U, C
U: UL, C: CSA, N: NK
See Omron sales representatives concerning operating conditions under which UL, CSA, and NK standards were met
(Aug. 1988).
