Index to parts and controls
For operational instructions, refer to the page indicated in square parentheses.
Front panel
STANDBY/ON
PHONES
STANDBY
A-905TX
INTEGRATED STEREO AMPLIFIER
TREBLEBASS BALANCE
POWER
OFF/1/2
—+ —+ L R
PRESENCE
ACOUSTIC
CD
MD TUNER
LINE/DVD
TAPE
CDR/PC
SOURCE DIRECT
DIRECT
DIRECT
TONE
INPUT
ON OFF
VOLUME
WIDE RANGE AMP TECHNOLOGY
Power/muting lamp [18, 21]
VOLUME control [19]
INPUT selector [19, 22]
ACOUSTIC PRESENCE
button/indicator [20]
BASS control [20]
TREBLE control [20]
BALANCE control [20]
POWER ON/OFF switch [18]
Input source indicators [19, 22]
PHONES jack [21]
STANDBY indicator [18]
Remote control sensor [17]
STANDBY/ON button [18]
SOURCE DIRECT selector [21]
SOURCE DIRECT
indicator [21]
