Onkyo CS-375D User Manual

> Before Start >Part Names > Install > Playback
Advanced Setup | Others
5
En
Rear Panel (CS-375D)
1. SPEAKERS terminals: Connect speakers with the supplied speaker cables.
2. DIGITAL IN OPTICAL jack: You can play the digital audio from an external device
such as a television connected with a digital optical cable.
3. LINE IN jacks: You can play the audio from an external device such as a television
connected with an analogue audio cable.
4. DAB/FM ANTENNA jack: Connect the supplied DAB/FM wire antenna.
5. AC INLET: Connect the supplied power cord.
   


Onkyo CS-375D Specifications

General

Coloration	Monochromatic
DAB antenna	Yes
Bluetooth profiles	A2DP, AVRCP
DAB III band range	174.928 - 239.2 MHz
Type	-
Cassette deck	No
Product color	Black
Number of optical discs	1 discs
Impedance	6 Ω
Speaker type	2-way
Frequency range	55 - 40000 Hz
RMS rated power	40 W
Woofer diameter	130 mm
Tweeter diameter	25 mm
Number of speakers	2
Signal-to-Noise Ratio (SNR)	90 dB
Total Harmonic Distortion (THD)	0.05 %
Power source	AC
Input voltage	220 - 240 V
Input frequency	50 - 60 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	20 W
Tuner type	Digital
FM band range	87.5 - 108 MHz
Supported radio bands	DAB+, FM
Preset stations quantity	40
Bluetooth version	4.1
Headphone outputs	1
Headphone connectivity	3.5 mm
Playback modes	Normal, Random, Repeat
Disc types supported	CD, CD-R, CD-RW
Playback disc formats	CD audio

Weight and Dimensions

Package type	Box
Package depth	464 mm
Package width	348 mm
Package height	250 mm
Package weight	9100 g
Main unit weight	2200 g
Main unit dimensions (WxDxH)	215 x 296.5 x 117 mm
