33
Specifications
Amplifier
Tuner
■ FM
■ AM
CD
USB
Bluetooth
Speakers D-T05
General
■ Audio input
■ Audio output
■ Other
Specifications and features are subject to change without
notice.
Rated output power
All channels:
15 watts minimum continuous
power per channel, 6 ohm loads,
2 channels driven at 1 kHz, with a
maximum total harmonic
distortion of 10% (FTC)
2ch
×
15 W (6 Ω, 1 kHz, 2ch driven)
(IEC)
THD + N (total harmonic distortion + N )
10 % (Power Rated)
0.5 % (1 kHz 1W)
Damping factor 60 (1 kHz, 8 Ω)
Input sensitivity and impedance
1000 mV/ 47 kΩ (LINE)
Frequency response 40 Hz–20 kHz/+0 dB, –3 dB
Tone control +10 dB, –10 dB ,100 Hz (BASS)
+10 dB, –10 dB, 10 kHz (TREBLE)
+4 dB/+8 dB, 80 Hz (S.BASS 1/2)
Signal to noise ratio 84 dB (LINE, IHF-A)
Speaker impedance 6–16 Ω
Tuning frequency range 87.5–107.9 MHz
Channel presets 30
Tuning frequency range 530–1710 kHz
Channel presets 30
Playable media CD and CD-R/CD-RW (music CDs
and MP3 CDs)
Playable media USB Flash Drive (MP3)
Version 2.1 + EDR
Profile A2DP 1.2
Codec SBC, AAC, aptX
Type 2 way bass-reflex
Impedance 6 Ω
Maximum input power 30 W
Output sound pressure level 82 dB/W/m
Frequency response 55 Hz–50 kHz
Crossover frequency 4.5 kHz
Cabinet capacity 3.4 liter
Dimensions (W
× H × D) 130 × 210 × 172 mm
(5-1/8" × 8-1/4" × 6-3/4")
(incl. grille and projection)
Weight 1.6 kg (3.5 lbs.)
Driver units 3-15/16" Cone Woofer
3/4" Balanced Dome Tweeter
Terminal Spring Type Color Coded
Other Magnetic shielding
Power supply AC 120 V, 60 Hz
Power consumption 30 W
No-sound Power Consumption 4.3 W (USB/FM/LINE)
7.6 W (CD)
Standby power consumption 0.4 W (when not charging iPod)
Dimensions (W
× H × D) 215 × 100 × 270 mm
(8-1/2" × 3-15/16" × 10-5/8")
Weight 2.4 kg (5.3 lbs.)
Analog input LINE
Analog output HEADPHONES, SPEAKERS,
SUBWOOFER
USB 2.0 HS
E39_CS-355_En_120614.book 33 ページ ２０１２年６月１４日 木曜日 午後１時４８分
