DV-SP406
CIRCUIT VOLTAGE CHART-1
MODE
PIN NO.
STOP PLAY
IC201(AM5869S)
1 1.392 1.397
2 1.705 1.637
3 1.375 1.436
4 1.393 1.396
5 1.243 1.238
6 0.01 0.01
7 0.02 0.02
8 5.589 5.53
9 0.001 0
10 0.001 0
11 2.729 2.771
12 2.729 2.687
13 2.733 2.686
14 2.733 2.757
15 2.739 2.701
16 2.739 2.725
17 2.734 3.725
18 2.734 1.656
19 5.598 5.55
20 3.277 3.253
21 5.598 5.54
22 0.001 0
23 1.395 1.734
24 3.275 3.251
25 5.574 5.51
26 1.392 1.391
27 1.392 1.391
28 0.019 3.197
29 0 0
30 0 0
IC601(MT1389S)
1 1.728 1.694
2 1.146 1.826
3 0.874 0.883
4 3.259 3.243
5 0.002 0.002
6 0.381 0.381
7 0.391 0.361
8 0.376 0.353
9 0.382 0.346
10 1.741 1.708
11 2.004 2.048
12 2.001 2.045
13 2.003 2.056
14 2.004 2.043
15 0.769 0.439
16 0.769 0.439
17 1.996 1.982
18 1.996 2.241
19 0 0.179
20 0 0.179
21 3.213 2.352
22 3.213 2.352
23 3.237 3.242
24 2.241 2.799
25 0.773 1.367
26 0.002 0.002
27 2.516 2.764
28 1.995 2.003
29 1.389 1.388
30 1.374 1.489
31 1.579 1.364
MODE
PIN NO.
STOP PLAY
32 1.578 1.359
33 2.431 1.824
34 2.593 1.828
35 2.196 1.684
36 1.391 1.834
37 1.391 1.466
38 0.008 0.009
39 1.391 1.391
40 1.388 1.382
41 1.387 1.422
42 0.002 0.001
43 1.859 1.856
44 0.011 0.008
45 0.011 0.008
46 3.281 3.272
47 0.002 0.002
48 0.819 0.794
49 1.859 1.854
50 0.002 0.002
51 0.971 0.864
52 0.971 0.717
53 3.261 0.017
54 3.241 0.022
55 1.848 1.851
56 1.954 2.257
57 1.884 2.054
58 1.947 2.239
59 1.694 1.604
60 1.785 1.783
61 1.816 2.346
62 1.997 1.652
63 0.127 0.125
64 0.012 0.015
65 3.285 3.277
66 3.285 3.276
67 1.393 1.093
68 1.759 1.806
69 1.251 3.043
70 2.245 3.006
71 1.249 3.131
72 0.305 0.712
73 2.466 1.706
74 2.759 1.332
75 0.011 0.013
76 0.011 0.013
77 2.079 1.895
78 0.011 0.012
79 1.369 1.523
80 1.705 1.803
81 0.002 0.002
82 0.585 0.854
83 0.971 0.956
84 1.561 1.616
85 1.547 1.469
86 1.683 0.974
87 0.021 0.024
88 1.171 1.127
89 1.368 1.117
90 0.002 0.002
91 0.025 0.024
92 1.998 1.846
93 1.876 1.828
94 3.254 3.257
MODE
PIN NO.
STOP PLAY
95 3.256 3.252
96 3.286 3.276
97 0.021 0.078
98 3.227 3.232
99 3.159 3.151
100 0.128 0.127
101 3.276 3.275
102 3.276 0
103 3.276 3.277
104 3.276 3.278
105 3.251 3.278
106 3.264 3.276
107 0.023 0.024
108 3.295 3.293
109 2.991 3.011
110 0.021 0.024
111 2.293 1.965
112 0.024 0.081
113 0.972 0.659
114 0.859 0.643
115 0.982 0.648
116 1.032 0.667
117 1.507 0.945
118 3.286 3.277
119 1.129 0.876
120 1.119 0.813
121 1.251 1.317
122 0.814 0.547
123 1.731 1.323
124 1.686 1.234
125 1.414 1.245
126 1.229 0.751
127 1.175 0.727
128 1.095 0.775
129 1.326 0.739
130 0.055 0.046
131 3.286 3.276
132 2.296 1.916
133 3.001 2.834
134 3.159 3.093
135 3.065 3.066
136 2.815 2.669
137 1.473 1.532
138 1.667 1.572
139 0.038 0.093
140 0.041 0.612
141 2.061 1.647
142 1.842 1.825
143 2.304 1.994
144 1.372 1.534
145 3.286 3.277
146 1.479 1.431
147 3.261 3.276
148 0.002 0.002
149 0.032 0.039
150 0.079 0.081
151 0.051 0.054
152 1.444 1.529
153 1.489 1.561
154 1.459 1.521
155 1.516 1.503
156 3.288 3.275
157 3.127 3.125
MODE
PIN NO.
STOP PLAY
158 3.266 3.258
159 4.82 4.82
160 1.842 1.829
161 4.84 4.84
162 0.021 0.017
163 0.002 0.002
164 1.331 1.33
165 3.099 3.086
166 3.099 3.086
167 0.345 0.208
168 0.001 0.001
169 0.001 0.001
170 0.001 0.001
171 0.003 0.004
172 1.842 1.831
173 0.002 0.001
174 0.002 0.002
175 0.001 0.001
176 0.002 0.003
177 0.002 0.002
178 1.845 1.832
179 0.002 0.002
180 0.002 0.002
181 0.002 0.002
182 0.637 0.032
183 0.701 0.034
184 0.003 0.003
185 0.496 0.127
186 3.251 3.237
187 2.614 2.567
188 0.003 0.002
189 0.676 0.659
190 3.251 3.238
191 0.498 0.281
192 0.002 0.002
193 1.212 1.207
194 1.289 1.203
195 3.251 3.239
196 0.016 0.018
197 0.016 0.018
198 0.024 0.022
199 0.024 0.022
200 0.024 0.023
201 0.128 3.248
202 0.027 0.023
203 0.024 1.523
204 0.023 1.608
205 0.023 1.635
206 2.915 1.321
207 3.266 3.256
208 0.023 0.024
209 0.023 0.024
210 0.018 0.021
211 0.019 3.218
212 1.831 1.829
213 0 0
214 2.945 2.936
215 1.539 1.533
216 3.241 3.251
217 1.892 1.698
218 0.002 0.002
219 0.002 0.002
220 0.002 0.002
