Specifications
Amplifier Section
Rated Output Power
All channels: 65 watts minimum continuous power per channel,
|QJONQCFU|EJCPPGNUFTKXGPHTQO*\VQM*\YKVJC
maximum total harmonic distortion of 0.7% (FTC)
90 watts minimum continuous power per channel, 6 ohm loads,
|EJCPPGNUFTKXGPCVM*\YKVJCOCZKOWOVQVCNJCTOQPKE
distortion of 0.7% (FTC)
(North American)
5 ch × 100 W at 6 ohms, 1 kHz, 1 ch driven of 1% (IEC) (Others)
Maximum Effective Output Power
5 ch × 120 W at 6 ohms, 1 kHz, 1 ch driven (JEITA) (Asian)
Dynamic Power (
¼
)
¼
IEC60268-Short-term maximum output power
 9ŝ(TQPV
9ŝ(TQPV
9ŝ(TQPV
THD+N (Total Harmonic Distortion+Noise)
0.7% (20 Hz - 20 kHz, half power)
Damping Factor
 (TQPVM*\ŝ
Input Sensitivity and Impedance (Unbalance)
 O8Mŝ.+0'
Rated RCA Output Level and Impedance
 O8Mŝ.+0'176
Maximum RCA Output Level and Impedance
 8Mŝ.+0'176
Frequency Response
5 Hz - 100 kHz/+1 dB, –3 dB (Direct mode)
Tone Control Characteristics
±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio
100 dB (LINE, IHF-A)
Speaker Impedance
 ŝŝ
Video Section
Input Sensitivity/Output Level and Impedance
 8RRŝ%QORQPGPV;
8RRŝ%QORQPGPV2
B
/C
B
, P
R
/C
R
)
8RRŝ%QORQUKVG
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, –3 dB
Tuner Section
FM Tuning Frequency Range
87.5 MHz - 107.9 MHz (North American and Taiwanese)
87.5 MHz - 108.0 MHz, RDS (Others)
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel
40
Bluetooth Section
Communication system
Bluetooth Specification version 2.1 + EDR (Enhanced Data Rate)
Maximum communication range
Line of sight approx. 15 m (
¼
)
Frequency band
2.4 GHz band (2.4000 GHz - 2.4835 GHz)
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible Bluetooth profiles
A2DP 1.2 (Advanced Audio Distribution Profile)
AVRCP 1.3 (Audio Video Remote Control Profile)
Supported Codecs
SBC
Transmission range (A2DP)
20 Hz - 20,000 Hz (Sampling frequency 44.1 kHz)
¼
The actual range will vary depending on factors such as obstacles
between devices, magnetic fields around a microwave oven, static
electricity, cordless phone, reception sensitivity, antenna’s
performance, operating system, software application, etc.
General
Power Supply
AC 120 V, 60 Hz (North American and Taiwanese)
AC 230 V, 50 Hz (European, Australian and British)
AC 220 - 240 V, 50/60 Hz (Others)
Power Consumption
3.2 A (North American and Taiwanese)
330 W (European, Australian and British)
360 W (Others)
0.2 W (Stand-by, North American and Taiwanese)
0.3 W (Stand-by, Others)
55 W (No-sound)
Dimensions (W × H × D)
435 mm × 150 mm × 321 mm
17-1/8" × 5-7/8" × 12-5/8"
Weight
7.6 kg (16.8 lbs.) (North American and Taiwanese)
8.1 kg (17.9 lbs.) (Others)

HDMI
Input
IN1 (BD/DVD), IN2 (CBL/SAT), IN3 (STB/DVR), IN4 (GAME), IN5 (PC),
IN6
Output
OUT
Video Resolution
Pass Through : 4K 60 Hz (YCbCr 4:2:0)
Audio Format
DTS-HD Master Audio, DTS-HD High Resolution Audio, Dolby TrueHD,
Dolby Digital Plus, DSD, Multichannel PCM
Supported
3D, Audio Return Channel, DeepColor, x.v.Color, LipSync, CEC (RIHD)

Video Inputs
Component
IN (GAME)
Composite
IN1 (CBL/SAT), IN2 (STB/DVR), IN3 (GAME), AUX

Video Outputs
Component
OUT
Composite
MONITOR OUT

Audio Inputs
Digital
OPTICAL (TV/CD)
COAXIAL 1 (BD/DVD), 2 (CBL/SAT)
Analog
BD/DVD, CBL/SAT, STB/DVR, GAME, PC, TV/CD, AUX

Audio Outputs
Analog
ZONE2 LINE OUT
SUBWOOFER PRE OUT
Speaker Outputs
FRONT L/R, CENTER, SURROUND L/R
Phones
PHONES (Front, ø 6.3)

Others
RI 1
USB 1
Specifications and features are subject to change without notice.

Onkyo HT-R393 Specifications

General

Brand	Onkyo
Model	HT-R393
Category	Receiver
Language	English
