Onkyo HT-R495 Service Manual

Diagnostic Function
5 4 3
2
1
6
D
C
A
B
D
C
A
B
5 4 3
2
1
6
TX-SR393/TX-SR494
HT-R398 / HT-R495
Service Information
Listening Mode Code List
00 NORMAL_LMD_BEGIN
01 LAST
02 PURE
03 DIRECT
04 STEREO
05 MONO
06 ORCHESTRA
07 UNPLUGGED
08 STUDIOMIX
09 TVLOGIC
0A ALLCHST
0B FULLMONO
0C TD
0D RPG
0E ACTION
0F ROCKBAND
10 SPORTS
11 WHOLEHOUSE
12 RPG_GENRE
13 ACTION_GENRE
14 ROCKBAND_GENRE
15 SPORTS_GENRE
12 NORMAL_LMD_END
20 SURR_LMD_BEGIN
21 SURR_20_PLII_MOVIE
22 SURR_20_PLII_MUSIC
23 SURR_20_PLII_GAME
24 SURR_20_PLIIX_MOVIE
25 SURR_20_PLIIX_MUSIC
26 SURR_20_PLIIX_GAME
27 SURR_20_PLIIZ
28 SURR_20_NEO6_MOVIE
29 SURR_20_NEO6_MUSIC
2A SURR_20_NEURAL_MUSIC
2B SURR_20_NEURAL_CINEMA
2C SURR_51_OFF
2D SURR_51_MTR
2E SURR_51_DSC
2F SURR_51_NEO6
30 SURR_51_EX
31 SURR_51_PLIIX_MOVIE
32 SURR_51_PLIIX_MUSIC
33 SURR_51_PLIIZ
34 SURR_51_NEURAL_CINEMA
35 SURR_20_NEOX_CINEMA
36 SURR_20_NEOX_MUSIC
37 SURR_20_NEOX_GAME
38 SURR_51_NEOX_CINEMA
39 SURR_51_NEOX_MUSIC
40 SURR_51_NEOX_GAME
41 SURR_20_DOLBY_SURR
42 SURR_51_DOLBY_SURR
43 SURR_LMD_END
48 DTSSS_LMD_BEGIN
49 DTSSS_20_NEO6_MUSIC
4A DTSSS_20_NEO6_CINEMA
4B DTSSS_51
4C DTSSS_LMD_END
50 THX_MUSIC_LMD_BEGIN
51 THX_20_PLII_MUSIC
52 THX_20_PLIIX_MUSIC
53 THX_20_PLIIZ_MUSIC
54 THX_20_NEO6_MUSIC
55 THX_20_NEURAL_MUSIC
56 THX_51_OFF_MUSIC
57 THX_51_MTR_MUSIC
58 THX_51_DSC_MUSIC
5A THX_51_PLIIX_MUSIC
5B THX_51_PLIIZ_MUSIC
5C THX_51_NEO6_MUSIC
5D THX_51_NEURAL_MUSIC
5E THX_20_NEOX_MUSIC
5F THX_51_NEOX_MUSIC
60 THX_20_DOLBY_SURR_MUSIC
61 THX_51_DOLBY_SURR_MUSIC
62 THX_MUSIC_LMD_END
70 THX_GAME_LMD_BEGIN
71 THX_20_PLII_GAME
72 THX_20_PLIIX_GAME
73 THX_20_PLIIZ_GAME
74 THX_20_NEURAL_GAMES
75 THX_51_OFF_GAMES
76 THX_51_MTR_GAMES
77 THX_51_DSC_GAMES
78 THX_51_PLIIX_GAME
79 THX_51_PLIIZ_GAMES
7A THX_51_NEO6_GAMES
7B THX_51_NEURAL_GAMES
7C THX_20_NEOX_GAMES
7D THX_51_NEOX_GAMES
7E THX_20_DOLBY_SURR_GAME
7F THX_51_DOLBY_SURR_GAME
80 THX_GAME_LMD_END
90
THX_CINEMA_LMD_BEGIN
91
THX_20_PLII_MOVIE
92
THX_20_PLIIX_MOVIE
93
THX_20_PLIIZ_CINEMA
94
THX_20_NEO6_MOVIE
95
THX_20_NEURAL_CINEMA
96
THX_51_OFF_CINEMA
97
THX_51_MTR_CINEMA
98
THX_51_DSC_CINEMA
99
THX_51_NEO6_CINEMA
9A
THX_51_PLIIX_MOVIE
9B
THX_51_PLIIZ_CINEMA
9C
THX_51_NEURAL_CINEMA
9D
THX_51_EX
9E
THX_20_NEOX_CINEMA
9F
THX_51_NEOX_CINEMA
A0
THX_20_DOLBY_SURR_CINEMA
A1
THX_51_DOLBY_SURR_CINEMA
A2
THX_CINEMA_LMD_END
B0
THX_U2GAME_LMD_BEGIN
B1
THX_20_PLII_SLCT2_GAME
B2
THX_20_PLIIZ_SLCT2_GAME
B3
THX_51_SLCT2_GAM
B4
THX_51_PLIIZ_SLCT2_GAME
B5
THX_U2GAME_LMD_END
B6
THX_U2MUSIC_LMD_BEGIN
B7
THX_51_SLCT2_MUS
B8
THX_51_PLIIZ_SLCT2_MUSIC
B9
THX_U2MUSIC_LMD_END
BA THX_U2CINEMA_LMD_BEGIN
BB THX_51_SLCT2_CIN
BC THX_51_PLIIZ_SLCT2_CINEMA
BD THX_U2CINEMA_LMD_END
D0
AUDYSSEY_LMD_BEGIN
D1
AUDYSSEY_20_PLII_MUSIC
D2
AUDYSSEY_20_PLIIX_MUSIC
D3
AUDYSSEY_20_NEO6_MUSIC
D4
AUDYSSEY_20_NEURAL_CINEMA
D5
AUDYSSEY_20_NEURAL_MUSIC
D6
AUDYSSEY_20_PLII_MOVIE
D7
AUDYSSEY_20_PLIIX_MOVIE
D8
AUDYSSEY_20_NEO6_MOVIE
D9
AUDYSSEY_20_PLII_GAME
DA
AUDYSSEY_20_PLIIX_GAME
DB
AUDYSSEY_51_OFF
DC
AUDYSSEY_51_PLIIX_MUSIC
DD
AUDYSSEY_51_PLIIX_MOVIE
DE
AUDYSSEY_51_NEO6
DF
AUDYSSEY_51_NEURAL_CINEMA
E0
// AUDYSSEY_51_NEURAL_MUSIC
E1
AUDYSSEY_51_EX
E2
AUDYSSEY_LMD_END
F0
SPECIAL_LMD_BEGIN
F1
TESTTONE
F2
TESTTHR
F3
TESTAUTO
F4
ASC
F5
FLASH
F6
DEBUGMODE
F7
FLASH2
F8
FLASH3
F9
FLASH4
FA
FLASH_CHECK
FB
SPECIAL_LMD_END
