Onkyo HT-R520 Service Manual

1/40 PAGE
EXPLODED VIEW PARTS LIST
<Notes>
(B) : Black model <DC> : Canadian model
(S) : Silver model <DD> : American model
(G) : Golden model <GK> : Korean model
<502>:TX-SR502 <GQ> : Hong kong model
<502E>:TX-SR502E(European model) <GR> : Chinese model
<8250>:TX-SR8250(Chinese model) <PA> : Australian model
<520>:HT-R520(American model & Canadian model) <PP> : European model
<PT> : Asian model (230-240V)
<WT> : World wide model
REF. NO. NAME DESCRIPTION Q'TY PART NO REMARKS
EXP
A001 F BRACKET (B)AS 1 27111360
(B)
EXP
A001 F BRACKET (S)AS 1 27111361
(S)
EXP
A001 F BRACKET (G)AS 1 27111362
(G)
EXP
A003 SCREW 3TTB+8B(CU) 32 801612
Except <502 GK>
EXP
A003 SCREW 3TTB+8B(CU) 33 801612
<502 GK>
EXP
A011 CHASSIS --- 1 27100443A
EXP
A015 HOLDER KGPS-10RF 1 27190813
EXP
A017 HOLDER KGLS-10RT 2 27190428A
EXP
A025 SCREW 4TTC+8C(BC) 4 830440089
EXP
A031 BUSHING S-RELIEF #2271 1 27300750
!
EXP
A033 HEAT SINK AS. 1 27160546
EXP
A034 TAPE TAPE(CLOTH-16U) ( 1) 29110083
EXP
A037 SCREW 3TTB+8B(CU)SR 1 801618
EXP
A039 SCREW 3SMH10W.SW+15B(CU) 12 801606
EXP
A040 IB CUSHION W15x3t TAPE ( 1) 28141585
EXP
A041 CUSHION --- 1 28141613
EXP
A050 COVER --- 1 28184831
(B)
EXP
A050 COVER --- 1 28184856
(S)
EXP
A050 COVER --- 1 28184857
(G)
EXP
A052 SCREW 3TTB+8B(BC) 6 838430088
(B)
EXP
A052 SCREW 3TTB+8B(UN) 6 838930088
(S),(G)
EXP
A053 LABEL (COVER) 1 29362772
<520>
EXP
A054 LEG LEG 4 27175319B
EXP
A056 CUSHION --- 8 28141494
EXP
A060 KNOB (VOL)AS 1 28325643
<8250> (G)
EXP
A060 KNOB (VOL)AS 1 28326197
(B)
EXP
A060 KNOB (VOL)AS 1 28326198
(S)
EXP
A060 KNOB (VOL)AS 1 28326199
<502> (G)
EXP
A062 CLEAR PLT --- 1 28192025B
(B)
EXP
A062 CLEAR PLT --- 1 28192027B
(S),(G)
EXP
A081 SCREW 3P+10FN(BC) 2 82143010
Except <DD, DC>
EXP
A082 KNOB (POW) 1 28325497A
<502 PA,WT>,<502E> (B)
EXP
A082 KNOB (POW) 1 28325499A
<502>,<8250> (G)
EXP
A082 KNOB (POW) 1 28325547A
<502 GR,PA,WT>,<502E> (S)
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
TX-SR502/E/8250/HT-R520
