HT-R591
<Note>
Parts marked by "NSP" are generally unavailable because
they are not in our Master Spare Parts List.
<Notes>
<MDC> : 120V,Canadian model
<MDS> : 120V,Brazilian model
<MMK> : 220/230-240V,Korean model
<MMQ> : 220/230-240V,Hong kong model
HT-R591
EXPLODED VIEW PARTS LIST
REF. NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
[SEMI CONDUCTOR]
Q6050 TR 2SC5198-O 1 2203063
Q6050 or TR 2SC4468-O ( 1) 2202523
Q6050 or TR 2SC4468-P ( 1) 2202526
Q6050 or TR 2SC5198-R ( 1) 2203062
Q6050A ISO SHEET AC238 2 223024
Q6050B ISO SHEET ISO SHEET 6 223050
Q6051 TR 2SC5198-O 1 2203063
Q6051 or TR 2SC4468-O ( 1) 2202523
Q6051 or TR 2SC4468-P ( 1) 2202526
Q6051 or TR 2SC5198-R ( 1) 2203062
Q6052 TR 2SC5198-O 1 2203063
Q6052 or TR 2SC4468-O ( 1) 2202523
Q6052 or TR 2SC4468-P ( 1) 2202526
Q6052 or TR 2SC5198-R ( 1) 2203062
Q6053 TR 2SC5198-O 1 2203063
Q6053 or TR 2SC4468-O ( 1) 2202523
Q6053 or TR 2SC4468-P ( 1) 2202526
Q6053 or TR 2SC5198-R ( 1) 2203062
Q6054 TR 2SC5198-O 1 2203063
Q6054 or TR 2SC4468-O ( 1) 2202523
Q6054 or TR 2SC4468-P ( 1) 2202526
Q6054 or TR 2SC5198-R ( 1) 2203062
Q6055 TR 2SC5198-O 1 2203063
Q6055 or TR 2SC4468-O ( 1) 2202523
Q6055 or TR 2SC4468-P ( 1) 2202526
Q6055 or TR 2SC5198-R ( 1) 2203062
Q6056 TR 2SC5198-O 1 2203063
Q6056 or TR 2SC4468-O ( 1) 2202523
Q6056 or TR 2SC4468-P ( 1) 2202526
Q6056 or TR 2SC5198-R ( 1) 2203062
Q6060 TR 2SA1941-O 1 2203053
Q6060 or TR 2SA1695-O ( 1) 2202513
Q6060 or TR 2SA1695-P ( 1) 2202516
Q6060 or TR 2SA1941-R ( 1) 2203052
Q6061 TR 2SA1941-O 1 2203053
Q6061 or TR 2SA1695-O ( 1) 2202513
Q6061 or TR 2SA1695-P ( 1) 2202516
Q6061 or TR 2SA1941-R ( 1) 2203052
Q6062 TR 2SA1941-O 1 2203053
Q6062 or TR 2SA1695-O ( 1) 2202513
Q6062 or TR 2SA1695-P ( 1) 2202516
Q6062 or TR 2SA1941-R ( 1) 2203052
Q6063 TR 2SA1941-O 1 2203053
Q6063 or TR 2SA1695-O ( 1) 2202513
Q6063 or TR 2SA1695-P ( 1) 2202516
Q6063 or TR 2SA1941-R ( 1) 2203052
Q6064 TR 2SA1941-O 1 2203053
Q6064 or TR 2SA1695-O ( 1) 2202513
Q6064 or TR 2SA1695-P ( 1) 2202516
Q6064 or TR 2SA1941-R ( 1) 2203052
Q6065 TR 2SA1941-O 1 2203053
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
NOTE : THE COMPONENTS IDENTIFIED BY THE MARK
! ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH PART
NUMBER SPECIFIED.
