Onkyo HT-R997 User Manual

8
Step2: Connect the Speakers
Standard Connections
Up to two powered subwoofers can be connected. The
same signal is output from each of the SUBWOOFER PRE
OUT jacks.
Make sure the exposed wires of the speakers
do not stick out of the speaker terminals when
connecting. If the exposed wires of the
speakers touch the rear panel or the + and –
wires touch each other, the protection circuit
will be activated.
> Before Start > Part Names >Install > Initial Setup > Playback
Blue
Tan Brown
Gray
Green
White
Red
a
b
a Speaker cable, b Subwoofer cable
SN29402830_HT-R997_BAS_En_1703XX.book 8 ページ ２０１７年３月１７日 金曜日 午前９時１８分

Onkyo HT-R997 Specifications

General

Audio output channels	7.1 channels
Audio formats supported	AIFF, ALAC, FLAC, WAV
Signal-to-Noise Ratio (SNR)	106 dB
Total Harmonic Distortion (THD)	0.08 %
AM band range	530 - 1710 kHz
FM band range	87.5 - 107.9 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
AC input voltage	120 V
AC input frequency	60 Hz
Power consumption (standby)	0.15 W
Power consumption (typical)	580 W
Subwoofer frequency range	20 - 100 Hz
Center speaker sensitivity	83 dB
Satellite speaker sensitivity	81 dB
Package weight	63000 g
Bluetooth version	4.1
Bluetooth profiles	A2DP, AVRCP
HDMI in	7
Component video (YPbPr/YCbCr) in	2
Disc types supported	No
Optical disc player type	Not included

Weight and Dimensions

Main unit weight	10000 g
Subwoofer weight	15500 g
Satellite speaker weight	3500 g
Main unit dimensions (WxDxH)	435 x 378 x 173.5 mm
Subwoofer dimensions (WxDxH)	380 x 429 x 444 mm
Front speaker dimensions (WxDxH)	158 x 199 x 433 mm
Center speaker dimensions (WxDxH)	433 x 199 x 158 mm
Satellite speaker dimensions (WxDxH)	200 x 169 x 275 mm
