EXPLODED VIEW PARTS LIST
Amp section
REF. NO. PART NO. DESCRIPTION
U1 1W232555-1A NAAF-7455-1A, Main circuit PC board assy
U2 1W232556-1A NAAF-7456-1A, Output level control PC board assy
U3 1W232557-1A NAETC-7457-1A, LED PC board assy
U4 1W232558-1A NAPS-7458-1A, Power transformer PC board assy
A1 27160467 Heat sink, SKW-205AMP
A2 801433 3SMS8W.SW+14B(BC),
Self tapping screw (6)
A3 27130745 Bracket (2)
A4 838130088 3TTB+8B, Self tapping screw (7)
A6 27141661 Retainer
A8 28184777 Cover
A9 28141322A Cushion
A10 28141475 Cushion t2X5X160 (2)
A11 28141476 Cushion t2X5X80 (2)
A41 27122963 Rear panel (Amp. Section)
A42 838430088 3TTB+8B(BC), Self tapping screw (13)
A43 830440109 4TTC+10C(BC), Self tapping screw (4)
A44 28141473 Cushion, t2X5X415 (2)
A45 28141474 Cushion, t2X5X195 (2)
A46 28141334 Cushion
A47 27301941 Cord bushing, KF-41
A48 28325405 Knob, OUTPUT LEVEL
E901 260208 Wire tie
Q515 * 2202524 2SC4468-Y or
* 2202523 2SC4468-O or
* 2202526 2SC4468-P or
* 2203062 2SC5198-R or
* 2203063 2SC5198-O, Transistor
Q516 * 2202514 2SA1695-Y or
* 2202513 2SA1695-O or
* 2202516 2SA1695-P or
* 2203052 2SA1941-R or
* 2203053 2SA1941-O, Transistor
Q515A, 223021 TBM-51W 9043, Isolation sheetQ516A
Q541 2202104 2SC3423-Y or
2202103 2SC3423-O
Q951 2202754 2SD1266-P
Q952 2202764 2SB941-P, Transistor
R602 4000144 PTH9M04-2.2K, Thermistor
T901 2301487 NPT-1396D, Power transformer
F901 252159 2A-UL/T-237 or
252253 2A-T/UL-ST2, Fuse
P901 253272HIT Power cord, AS-UC-6#18
CAUTION: Replacement of the transistor of mark , if necessary,
must be made from the same beta group (HFE) as the
original type.
*
NOTE: THE COMPONENTS IDENTIFIED BY MARK
ARE CRITICAL FOR RISK OF FIRE AND
ELECTRIC SHOCK. REPLACE ONLY WITH
PART NUMBER SPECIFIED.
A50 28141503 Cushion
HTP-120
