Onkyo SKW 50 User Manual

䇭䋱䋮Confirmin
g
o
p
erations
䋱䋭䋱 Confirmin
g
o
p
eration of auto standb
y
On/Off
a. Turn AUTO STANDBY switch on.
b. After no in
p
ut condition continues more than 10 seconds, short-circuited the terminal of P604.
Confirm that the indicator chan
g
es from red to
g
reen.
c. Next short-circuited the terminal of P604.
䇭䋲䋮Ad
j
ustment of idlin
g
current
a.
Ad
j
ust the trimmin
g
resistor R544 so that the volta
g
e of P531 becomes 0.25mV.
(
Auto Standb
y
Switch is OFF
p
osition. No in
p
ut and no load.䋩
b. After 5 minuters, read
j
ust R544 so that the volta
g
e becomes 4mV.
䇭
ADJUSTMENT PROCEDURES
R544
4
4
P531
P
6
2
3
P
604
Confirm that indicator changes from green to red.
SKW-50
