TX-8020
SCHEMATIC DIAGRAMS-09(PART-9)
SWITCH(STANDBY) SECTION
TX-8020
TITLE
APPROVCHECKDESIGN SHEET
DRAWING No.
GNDDIS
LEDSTBY
KEY0_2
JL703B
NSCT-3P874
123
D703
R718
S708
BADIS-1436
STBY
TX-8020
DISPLAY SECTION (Part-9)
RC-202985
H.Suda
2013.04.09
K.Ikeda S.Murayama
2013.04.09 2013.04.09
MODEL NO. TX-8020 SCHEMATIC DIAGRAM (PART-9) DISPLAY SECTION
9 14
U0031 SWITCH(STANDBY) PC BOARD
A
1
2
3
4
B C D E

Onkyo TX-8020B Specifications

General

Receiver type	stereo
Audio output channels	- channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	1 %
Power output per channel (20-20KHz@8 Ohm)	90 W
Connectivity technology	Wired
Speakers connectivity type	-
Product color	Black
Apple docking compatibility	Not supported
AC input frequency	50 Hz
Power consumption (typical)	170 W
Package weight	9600 g
HDMI in	0
Audio (L/R) in	5
Digital audio coaxial in	2
Digital audio optical in	1
Multichannel audio input type	Terminals
Ethernet LAN	No
RDS features	PS, PTY, RT, TP
Supported radio bands	AM, FM
Preset stations quantity	40

Weight and Dimensions

Depth	150 mm
Width	435 mm
Height	328.5 mm
Weight	7300 g
