TX-8222
TUNER UNIT ENG07506QFEX 240159 <A>
TUNER UNIT FAE485-E11EU 240154 <P>
PRINTED CIRCUIT BOARD-PARTS LIST
CIRCUIT NO. PART NAME DESCRIPTION PART NO. REMARKS
U01
U012
U013
U014
U015
U016
U017
Q852 FL TUBE 16-BT-128GNYK 212258A
Q601 IC
M3062MWP-B01FP(MASK) 22242449R3
Q701 IC S-812C56AUA-C3K 22242207R2
Q706 IC 78M56(NJM78M56FA) 222780565JRC
Q851 IC M66005-0001AHP 22242208R3
Q855 IC LM61CIZ 22242212
Q602,Q703 TR RN1404 2214490R2
Q603,Q705 TR RN2402 2214530R2
Q853 TR 2SC2712-GR 2213145R2
Q912 TR KTC3199-GR 2215864
D601,D602 C-DIODE 1SS352 or 223234R2 or
D603 C-DIODE 1SS355 223269R2
D604 ZENER D UDZS5.1B 224550510R2
D701,D702,D703 C-DIODE 1SS352 or 223234R2 or
D704,D705,D706 C-DIODE 1SS355 223269R2
C-DIODE 1SS352 or 223234R2 or
C-DIODE 1SS355 223269R2
D851 ZENER D UDZS8.2B 224550820R2
D853 LED SLI-343URC-TE7 225449
D854 SPCF D SIR-34ST3F 225456
D901,D902,D903 C-DIODE 1SS352 or 223234R2 or
D904,D905,D906 C-DIODE 1SS355 223269R2
D908,D909 C-DIODE 1SS352 or 223234R2 or
D912,D913 C-DIODE 1SS355 223269R2
D914 ZENER D UDZS5.1B 224550510R2
C-DIODE 1SS352 or 223234R2 or
C-DIODE 1SS355 223269R2
NAPS-8880-1M/1N/1P
NAETC-8881-1M/1N/1P
NAETC-8882-1M/1N/1P
Microprocessor PCB AS
Display circuit PCB AS
Thermal detector PCB AS
Holder PCB
Primary circuit PCB AS
Transformer terminal PCB AS
Headphone terminal PCB AS
NADG-8876-1M/1N/1P
NADIS-8877-1M/1N/1P
NAETC-8878-1M/1N/1P
NAETC-8879-1M/1N/1P
D707,D708,D713
D991,D992
