Onkyo TX-8222 User Manual

TX-8222
JL711A,JL716B WIRE HOL NSCT-3P894 25051107
JL911A WIRE HOL NSCT-6P877 25051090
JL911B WIRE TRAP NPLG-6P589 25055627
P901A PLUG NPLG-2P631 25055675
!
P504 CRIMP AS CRIMP AS 2061712200UL
P911 CRIMP AS CRIMP AS 2069943351UL
P912 CRIMP AS CRIMP AS 2069943459UL
P991 RETAINER MET37-0002 27142009
Q855A RETAINER (PTH) 27141884-1
P708 TRM(SCREW) GND TERMINAL 25065425
Q852A HOLDER (FL) 27191222B
U02
U022
U023
U026
Q301 IC NJM4558D-X 222502
Q302 IC TC9273CNG-010 22242335
D491 IC NJM2068L-D 22240250
Q481 IC TA7291SG(5_J) 22240239
IC 78M12HF or 222780125 or
IC NJM78M12FA or 222780125JRC or
IC MPC78M12HF 222780125NEC
Q922 IC 79M12HF 222790125
TR RN1241-A(TPE4_F) or 2213631 or
TR RN1241-B 2213632
TR KRA102M or 2215770 or
TR DTA114ES 2213510
Q501,Q502 TR 2SC2240-BL(TPE2_F) 2211406
Q503,Q504 TR 2SC2240-BL(TPE2_F) 2211406
TR 2SC2240-BL(TPE2_F) or 2211406 or
TR 2SC2240-GR 2211405
Q507,Q508,Q509 TR 2SA949-Y(TPE6_F) or 2211354 or
Q510,Q513,Q514 TR 2SA949-O(TPE6_F) 2211353
TR 2SC2229-Y(TPE6_F) or 2211634 or
TR 2SC2229-O(TPE6_F) 2211633
Q517,Q518 TR 2SC5171(ONK_Q) 2203010
Q519,Q520 TR 2SA1930(ONK_Q) 2203000
TR 2SC2229-Y(TPE6_F) or 2211634 or
NAAF-8886-1M/1N
NAPS-8887-1M/1N
NAAF-8888-1M/1N
NAETC-8891-1M/1N
Main circuit PCB AS
Transformer terminal PCB AS
Volume PCB AS
Clamper PCB AS
Q921
Q493
Q491,Q492
Q505,Q506
Q515,Q516
Q527 Q528

Onkyo TX-8222 Specifications

General

Brand	Onkyo
Model	TX-8222
Category	Stereo Receiver
Language	English
