General Specifications
■ Amplifier Section
Rated Output Power (FTC) (North American)
With 8 ohm loads, both channels driven, at 1 kHz;
rated 135 watts per channel minimum RMS power,
with no more than 0.08% total harmonic distortion
from 250 milliwatts to rated output.
Surround Mode Output Power (＊)
(6 ohms, 1 kHz THD 0.9%) 175 W per channel
＊ Reference output for each speakers.
Depending on the source and the listening mode
settings, there may be no sound output.
Maximum Effective Output Power (North American)
250 W at 6 Ω, 1 kHz, 1 ch driven of 10% THD
Maximum Effective Output Power (JEITA) (China)
9 ch × 310 W at 4 ohms, 1 kHz, 1 ch driven of 10%
THD
Dynamic Power (＊)
＊ IEC60268-Short-term maximum output power
320 W (3 Ω, Front)
270 W (4 Ω, Front)
160 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.04% (1 kHz, 100 W, 8 Ω)
Input Sensitivity and Impedance
200 mV/82 kΩ (LINE (RCA))
3.5 mV/47 kΩ (PHONO MM)
Rated RCA Output Level and Impedance
1 V/330 Ω (PRE OUT)
1 V/330 Ω (SUBWOOFER PRE OUT)
200 mV/1.2 kΩ (ZONE LINE OUT)
2 V/1.2 kΩ (ZONE PRE OUT)
Phono Overload
70 mV (MM 1 kHz 0.5%)
Tone Control Characteristics
±10 dB, 100 Hz (BASS)
±10 dB, 10 kHz (TREBLE)
Signal to Noise Ratio
107 dB (IHF-A, LINE IN, SP OUT)
90 dB (IHF-A, PHONO IN, SP OUT)
Speaker Impedance
4 Ω - 16 Ω
Headphone Output Impedance
43 Ω
Headphone Rated Output
55 mW (32 Ω, 1 kHz, 10% THD)
■ Video Section
Signal level
1 Vp-p/75 Ω (Composite Video)
1 Vp-p/75 Ω (Component Video Y)
0.7 Vp-p/75 Ω (Component Video B/R)
Maximum resolution supported by component video
480i/576i
■ Tuner Section
FM Tuning Frequency Range
87.5 MHz - 107.9 MHz (North American)
87.5 MHz - 108.0 MHz, RDS (China)
AM Tuning Frequency Range
530 kHz - 1710 kHz (North American)
522/530 kHz - 1611/1710 kHz (China)
Preset Channel
40
■ Network Section
Ethernet LAN
10BASE-T/100BASE-TX
Wireless LAN
IEEE 802.11 a/b/g/n standard
(Wi-Fi
R
standard)
5 GHz/2.4 GHz band
■ BLUETOOTH Section
Communication system
BLUETOOTH Specification version 4.1+LE
Frequency band
2.4 GHz band
Modulation method
FHSS (Freq Hopping Spread Spectrum)
Compatible BLUETOOTH profiles
A2DP 1.2
AVRCP 1.3
HOGP-Host (Client)
HOGP-HID Device (Server)
HID Service (HIDS)
Supported Codecs
SBC
AAC
Transmission range (A2DP)
20 Hz - 20 kHz (Sampling frequency 44.1 kHz)
Maximum communication range
Line of sight approx. 15 m (＊)
½
The actual range will vary depending on factors
such as obstacles between devices, magnetic fields
around a microwave oven, static electricity, cordless
phone, reception sensitivity, antenna's performance,
operating system, software application, etc.
■ General
Power Supply
AC 120 V, 60 Hz (North American)
AC 220 - 230 V, 50/60 Hz (China)
Power Consumption
310 W
Power Consumption (Standby mode)
0.1 W (Full Standby mode)
1.7 W (Network Standby mode, Wired) (＊1)
2.0 W (Network Standby mode, Wireless) (＊2)
1.6 W (Bluetooth Wakeup mode) (＊3)
0.1 W (CEC standby mode) (＊4)
2.0 W (Standby mode, All on) (＊5)
＊1. Network Standby: On, Wi-Fi: Off (Wired), Bluetooth:
Off
＊2. Network Standby: On, Wi-Fi: On, Bluetooth: Off
＊3. Network Standby: Off, Wi-Fi: Off (Wired), Bluetooth:
