On, Auto Input Change: On, Bluetooth Wakeup: On
＊4. HDMI CEC: On, HDMI Standby Through: Auto(Eco)
＊5. Network Standby: On, Wi-Fi: On, Bluetooth: On, Auto
Input Change: On, Bluetooth Wakeup: On, HDMI
CEC: On, HDMI Standby Through: Auto (Eco)
Dimensions (W × H × D)
435 mm × 201 mm × 453 mm
17-1/8" × 7-15/16" × 17-13/16"
Weight
16.3 kg (35.9 lbs.) (North American)
16.6 kg (36.6 lbs.) (China)
■ HDMI
Input
IN1 (BD/DVD), IN2 (CBL/SAT), IN3 (STRM BOX),
IN4 (GAME), IN5 (PC), IN6, IN7, AUX INPUT HDMI
(front)
Output
OUT MAIN (ARC), OUT ZONE 2/SUB
Supported
Deep Color, x.v.Color™, LipSync, Audio Return
Channel, 3D, 4K 60 Hz, CEC, Extended Colorimetry
(sYCC601, Adobe RGB, Adobe YCC601), Content
Type, HDR
Audio Format
Dolby Atmos, Dolby TrueHD, Dolby Digital, Dolby
Digital Plus, DTS, DTS:X, DTS-HD Master Audio,
DTS-HD High Resolution Audio, DTS 96/24, DTS-
ES, DTS Express, DSD, PCM
Maximum Video Resolution
4k 60 Hz (YCbCr 4:4:4)
■ Video Inputs
Component
IN1 (BD/DVD), IN2 (GAME)
Composite
IN1 (CBL/SAT), IN2 (STRM BOX)
■ Compatible input resolutions
HDMI input
4K, 1080p/24, 1080p, 1080i, 720p, 480p/576p
Component input
480i/576i
Composite input
480i/576i
•
The output from the HDMI OUT jack to the TV is the
same resolution as the input.
■ Audio Inputs
Digital
OPTICAL 1 (GAME), 2 (CD)
COAXIAL 1 (BD/DVD), 2 (CBL/SAT)
Analog
CBL/SAT, STRM BOX, BD/DVD, GAME, CD, TV,
PHONO
■ Audio Outputs
Analog
ZONE2 PRE/LINE OUT
ZONE3 PRE/LINE OUT
PRE OUT (FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R, HEIGHT 1 L/R, HEIGHT 2
L/R, 2 SUBWOOFER)
Speaker Outputs
FRONT L/R, CENTER, SURROUND L/R,
SURROUND BACK L/R, HEIGHT 1 L/R, HEIGHT 2
L/R
(North American models are banana plug ready)
Phones
PHONES (Front, ø 6.3 mm, 1/4")
■ Others
Setup Mic : 1 (Front)
USB : 1 (Ver. 2.0, 5 V/1 A)
Ethernet : 1
RS232 : 1
IR IN : 1
12V TRIGGER OUT : 2 (A:100 mA, B:25 mA)
Specifications and features are subject to change without
notice.
