TX-SR303/303E
SPECIFICATION
Audio Outputs
Analog Outputs TAPE, VIDEO1
Subwoofer Pre Outputs 1
Speaker Outputs SP-A (L, R, C, SL, SR) + SP-B (L, R)
Phones 1
Specifications and features are subject to change without notice.
Power Supply North American: AC 120 V, 60 Hz
European: AC 230-240 V, 50 Hz
Power Consumption North American: 4.2 A
European: 360 W
Stand-by Power Consumption North American: 0.1 W
European: 0.2 W
Dimensions
(W x H x D) 435 x 150 x 369 mm
17-1/8" x 5-7/8" x 14-1/2"
Weight North American and European: 8.5 kg
18.7 lbs.
Video Outputs
Composite MONITOR OUT, VIDEO1
Audio Inputs
Digital Inputs Optical: 1
Coaxial: 1
Analog Inputs DVD(MULTICHANNEL), VIDEO1,
VIDEO2, VIDEO3, TAPE, CD
Multichannel Inputs 6
General
Power Output
2 channel driven: North American: 65 W + 65 W
(8 , 20Hz-20kHz, FTC)
European: 90 W + 90 W (6 , 1kHz, DIN)
Dynamic Power 160 W + 160 W (3 , Front)
125 W + 125 W (4 , Front)
85 W + 85 W (8 , Front)
THD
(Total Harmonic Distortion) 0.08% (Power Rated)
Damping Factor 60 (Front, 1kHz, 8 )
Input Sensitivity and Impedance 200 mV/ 47 k (LINE)
Output Level and Impedance 200 mV/ 470 (REC OUT)
Frequency Response 10 Hz-100 kHz/ +1 dB-3 dB (Direct
mode)
Tone Control 10 dB, 50 Hz (BASS)
10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE IHF-A)
Speaker Impedance 6 -16
Amplifier Section
Input Sensitivity/Output Level
and Impedance 1 Vp-p /75 (Composite)
Video Section
FM
Tuning Frequency Range North American: 87.5 MHz-107.9 MHz
European: 87.5 MHz-108.0 MHz
Usable Sensitivity Stereo: 17.2 dBf 2 V(75 IHF)
Mono: 11.2 dBf 1 V(75 IHF)
Signal to Noise Ratio Stereo: 70 dB (IHF-A)
Mono: 76 dB (IHF-A)
THD Stereo: 0.3% (1kHz)
Mono: 0.2% (1kHz)
Frequency Response 30 Hz-15 kHz / 1 dB
Stereo Separation 45 dB (1kHz)
AM
Tuning Frequency Range North American: 530 kHz-1710 kHz
European: 531 kHz-1611 kHz
Usable Sensitivity 30 V
Signal to Noise Ratio 40 dB
THD 0.70%
Tuner Section
Video Inputs
Composite DVD, VIDEO1, VIDEO2, VIDEO3
