Onkyo TX-SR303 Service Manual

3/24 PAGE
EXP
Q6062 TR 2SA1941-O 1 2203053
<303>
EXP
Q6062 or TR 2SA1941-R ( 1) 2203052
<303>
EXP
Q6062 or TR MP100S-O ( 1) 2203643
<303>
EXP
Q6062 or TR MP100S-P ( 1) 2203646
<303>
EXP
Q6062 or TR MP100S-Y ( 1) 2203644
<303>
EXP
Q6062 TR 2SA1941-O 1 2203053
<303E>
EXP
Q6062 or TR 2SA1941-R ( 1) 2203052
<303E>
EXP
Q6062 or TR MP100S-O ( 1) 2203643
<303E>
EXP
Q6062 or TR MP100S-P ( 1) 2203646
<303E>
EXP
Q6062 or TR MP100S-Y ( 1) 2203644
<303E>
EXP
Q6063 TR KTA1962A-O 1 2203943
<303>
EXP
Q6063 or TR KTA1962A-R ( 1) 2203942
<303>
EXP
Q6063 or TR MP100S-O ( 1) 2203643
<303>
EXP
Q6063 or TR MP100S-P ( 1) 2203646
<303>
EXP
Q6063 or TR MP100S-Y ( 1) 2203644
<303>
EXP
Q6063 TR KTA1962A-O 1 2203943
<303E>
EXP
Q6063 or TR KTA1962A-R ( 1) 2203942
<303E>
EXP
Q6063 or TR MP100S-O ( 1) 2203643
<303E>
EXP
Q6063 or TR MP100S-P ( 1) 2203646
<303E>
EXP
Q6063 or TR MP100S-Y ( 1) 2203644
<303E>
EXP
Q6064 TR KTA1962A-O 1 2203943
<303>
EXP
Q6064 or TR KTA1962A-R ( 1) 2203942
<303>
EXP
Q6064 or TR MP100S-O ( 1) 2203643
<303>
EXP
Q6064 or TR MP100S-P ( 1) 2203646
<303>
EXP
Q6064 or TR MP100S-Y ( 1) 2203644
<303>
EXP
Q6064 TR KTA1962A-O 1 2203943
<303E>
EXP
Q6064 or TR KTA1962A-R ( 1) 2203942
<303E>
EXP
Q6064 or TR MP100S-O ( 1) 2203643
<303E>
EXP
Q6064 or TR MP100S-P ( 1) 2203646
<303E>
EXP
Q6064 or TR MP100S-Y ( 1) 2203644
<303E>
EXP
T901 P TRANS NPT-1514D 1 2301793
!, <303>
EXP
T901 P TRANS NPT-1514P 1 2301794
!, <303E>
EXP
U01 DISPLAY PC board ass'y NADIS-8513-1A 1 1B068513-1A
!, <303>
EXP
U01 DISPLAY PC board ass'y NADIS-8513-1X 1 1B068513-1X
!, <303E>
EXP
U02 DSP PC board ass'y NADG-8514-1A 1 1B068514-1A
!, <303>
EXP
U02 DSP PC board ass'y NADG-8514-1X 1 1B068514-1X
!, <303E>
EXP
U03 SWITCH PC board ass'y NASW-8515-1A 1 1B068515-1A
!, <303>
EXP
U03 SWITCH PC board ass'y NASW-8515-1X 1 1B068515-1X
!, <303E>
EXP
U04
HEADPHONE JACK PC board ass'y
NAETC-8516-1A 1 1B068516-1A
!, <303>
EXP
U04
HEADPHONE JACK PC board ass'y
NAETC-8516-1X 1 1B068516-1X
!, <303E>
EXP
U05 AMPLIFIER PC board ass'y NAAF-8523-1A 1 1B068523-1A
EXP
U06
SEC. TERMINAL-2 PC board ass'y
NAPS-8524-1A 1 1B068524-1A
EXP
U08
THERMAL SENSOR PC board ass'y
NAETC-8526-1A 1 1B068526-1A
EXP
U09 HOLDER PC board ass'y NAETC-8527-1A 1 1B068527-1A
EXP
U11 POWER SUPPLY-1 PC board ass'y NAPS-8544-1A 1 1B068544-1A
<303>
EXP
U11 POWER SUPPLY-1 PC board ass'y NAPS-8544-1J 1 1B068544-1J
<303E>
EXP
U13 POWER SUPPLY-2 PC board ass'y NAPS-8546-1A 1 1B068546-1A
<303>
EXP
U13 POWER SUPPLY-2 PC board ass'y NAPS-8546-1J 1 1B068546-1J
<303E>
EXP
U14 SEC. TERMINAL-1 PC board ass'y NAPS-8547-1A 1 1B068547-1A
<303>
EXP
U14 SEC. TERMINAL-1 PC board ass'y NAPS-8547-1J 1 1B068547-1J
<303E>
EXP
U15
SPEAKER TERMINAL PC board ass'y
NAETC-8548-1A 1 1B068548-1A
<303>
EXP
U15
SPEAKER TERMINAL PC board ass'y
NAETC-8548-1J 1 1B068548-1J
<303E>
EXP
U16 VIDEO PC board ass'y NAVD-8549-1A 1 1B068549-1A
<303>
EXP
U16 VIDEO PC board ass'y NAVD-8549-1J 1 1B068549-1J
<303E>
EXP
U17
DRIVER AMPLIFIER PC board ass'y
NAAF-8550-1A 1 1B068550-1A
<303>
EXP
U17
DRIVER AMPLIFIER PC board ass'y
NAAF-8550-1J 1 1B068550-1J
<303E>
EXP
U18 TUNER UNIT TFCE1U114B 1 240134A
<303>
EXP
U18 TUNER UNIT TFCE1E512A 1 240135
<303E>
TX-SR303/303E
PC BOARD PARTS LIS
T
U01 DISPLAY PC BOARD (NADIS-8513-1A/1X)
U02 DSP PC BOARD (NADG-8514-1A/1X)
U03 SWITCH PC BOARD (NASW-8515-1A/1X)
U04 HEADPHONE JACK PC BOARD (NAETC-8516-1A/1X)
CIRCUIT N
O
NAME DESCRIPTION Q'TY PART NO REMARKS
PCB1
U131 PHT CP GP1FAV51RKF5 1 24120129
PCB1
U821 REMO SENS GP1UM281XKVFH=16MM 1 241361
PCB1
Q111 IC BU1924FS 1 22242120R2
<303E>
PCB1
Q131 IC 74HCU04F 1 222740046R2
PCB1
Q151 IC TC74VHC541FT 1 22274541ER2TO
PCB1
Q151 or IC SN74AHC541PWR ( 1) 22274541IR2TI
PCB1
Q152 IC TC74HCT7007AF 1 222740077R2TO
PCB1
Q171 IC TC7WU04FU 1 22240935R2
PCB1
Q201 IC CS494003CQZ 1 22242039R3
