Onkyo TX-SR313 User Manual

Appendix
En-65
Specifications
Amplifier Section
Video Section
Tuner Section
General
■ HDMI
■ Video Inputs
■ Video Outputs
■ Audio Inputs
■ Audio Outputs
■ Others
Specifications and features are subject to change
without notice.
Rated Output Power
All channels: (North American)
65 watts minimum continuous power per
channel, 8 ohm loads, 2 channels driven
from 20 Hz to 20 kHz, with a maximum
total harmonic distortion of 0.7% (FTC)
90 watts minimum continuous power per
channel, 6 ohm loads, 2 channels driven at
1 kHz, with a maximum total harmonic
distortion of 0.9% (FTC)
(Others)
5 ch × 100 W at 6 ohms, 1 kHz,
1 ch driven of 1% (IEC)
Maximum Effective Output Power
(Australian and Asian)
5 ch × 120 W at 6 ohms, 1 kHz, 1 ch driven
(JEITA)
Dynamic Power
*
*
IEC60268-Short-term maximum output power
160 W (3 Ω, Front)
125 W (4 Ω, Front)
85 W (8 Ω, Front)
THD+N (Total Harmonic Distortion+Noise)
0.08% (20 Hz - 20 kHz, half power)
Damping Factor 60 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance (Unbalance)
200 mV/47 kΩ (LINE)
Rated RCA Output Level and Impedance
200 mV/2.2 kΩ (REC OUT)
Maximum RCA Output Level and Impedance
2 V/2.2 kΩ (REC OUT)
Frequency Response 5 Hz - 100 kHz/+1 dB, –3 dB (DSP bypass)
Tone Control Characteristics
±10 dB, 50 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 100 dB (LINE, IHF-A)
Speaker Impedance 6 Ω - 16 Ω
Input Sensitivity/Output Level and Impedance
1 Vp-p/75 Ω (Component Y)
0.7 Vp-p/75 Ω (Component PB/CB, PR/CR)
1 Vp-p/75 Ω (Composite)
Component Video Frequency Response
5 Hz - 100 MHz/+0 dB, –3 dB
FM Tuning Frequency Range
(North American)
87.5 MHz - 107.9 MHz
(Taiwanese)
87.5 MHz - 108.0 MHz
(Others)
87.5 MHz - 108.0 MHz, RDS
AM Tuning Frequency Range
522/530 kHz - 1611/1710 kHz
Preset Channel 40
Power Supply (North American and Taiwanese)
AC 120 V, 60 Hz
(European) AC 230 V, 50 Hz
(Others) AC 220 - 240 V, 50/60 Hz
Power Consumption (North American and Taiwanese) 3.4 A
(European) 300 W
(Others) 340 W
No-sound Power Consumption
(North American, European and
Taiwanese) 40 W
(Others)
35 W (230 V)
40 W (240 V)
Stand-by Power Consumption
(North American and Taiwanese) 0.2 W
(Others) 0.3 W
Dimensions (W × H × D)
435 mm × 150 mm × 318 mm
17-1/8" × 5-7/8" × 12-1/2"
Weight 7.6 kg (16.8 lbs.)
Input IN 1, IN 2, IN 3, IN 4
Output OUT
Video Resolution 1080p
Audio Format Dolby TrueHD, DTS-HD Master Audio,
DVD-Audio, DSD
Supported 3D, Audio Return Channel, DeepColor,
x.v.Color, LipSync, CEC (RIHD)
Component IN 1, IN 2
Composite BD/DVD, VCR/DVR, CBL/SAT, GAME,
AUX
Component OUT
Composite MONITOR OUT, VCR/DVR OUT
Digital Optical: 2
Coaxial: 1
Analog BD/DVD, VCR/DVR, CBL/SAT, GAME,
TV/CD, AUX
Analog VCR/DVR
Subwoofer Pre Output 1
Speaker Outputs SP-A (L, R, C, SL, SR) + SP-B (L, R)
Phones 1 (6.3 ø)
USB 1 (Front)
RI 1

Onkyo TX-SR313 Specifications

General

Receiver type	Surround
Audio output channels	5.1 channels
Power output per channel (1KHz@6 Ohm)	100 W
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	4
AC (power) in	Yes
Composite video in	5
Digital audio coaxial in	1
Component video (YPbPr/YCbCr) in	2
Connectivity technology	Wired
Speakers connectivity type	-
Ethernet LAN	No
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Preset stations quantity	40
Product color	Black
Audio decoders	Dolby TrueHD, DTS-HD Master Audio
Apple docking compatibility	Not supported
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	300 W
Package weight	9600 g

Weight and Dimensions

Depth	318 mm
Width	435 mm
Height	150 mm
Weight	7600 g
