Oracle Database Appliance X6-2-HA Status Indicators
22 Oracle Database Appliance Service Manual • June 2017
Callout Indicator/LED: Color State Meaning
■ GRN=10G:
■ On – Green for 10GbE link; amber for 1GbE link.
■ Off – No function.
■ ACT/LINK (A or B):
■ On – Green for link up.
■ Off – No link.
■ Blinking – Green for packet activity.
8 NET 0-3 ports: green/amber 100/1000/10000 BASE-T Ethernet management interface.
Top left activity indicator:
■ On – No function.
■ Off – No activity.
■ Blinking – Packet activity.
Top right link indicator:
■ On – Amber for 1000Base-T link; green for 10GBBase-T link.
■ Off – 100BASE-T link.
■ Blinking – No function.
Oracle Database Appliance X6-2-HA Storage Shelf
Indicators
Storage shelves are supported with Oracle Database Appliance X6-2-HA. They include controls
and indicators on the front panel, hard drives, SSD drives, power supplies, and SAS I/O
modules.
Storage Shelf Front Panel Status Indicators
The following figure shows the controls and indicators on the for the Oracle Database
Appliance X6-2-HA storage shelf (DE3-24C) front panel and drives.
Note - The 2 or 3 character LED enclosure ID display panel on the front of the storage shelf is
not used with the Oracle Database Appliance product. Any numbers or letters displayed in this
panel other than zeros could indicate a fault with either the panel, its cabling (neither of which
are customer replaceable), or some other storage shelf component.
