10. Plug the power cord into a power outlet, and then touch the power button for two
seconds to power on the Workstation 820.
Mounting the Workstation 820 on the Low Profile Stand
1. Unpack the Low Profile Stand box. Retain the box and foam for potential storage
or shipping needs.
2. Insert the Workstation 820 into the four openings on the Low Profile Stand
mounting plate until it clicks into place, and then use the Oracle 2.5mm hex key or
equivalent to lock the assembly (optional).
Figure 4-12 Mounting the Workstation 820 on the Low Profile Stand
3. Connect the Workstation 8 Series power supply to the Power In port on the
Workstation 820. Follow the cable routing path as shown below.
Note:
Workstation 8 Series ports and cables are color-coded to simplify
assembly.
Chapter 4
Mounting the Workstation 820 on the Low Profile Stand
4-8
